MICRO DETECTORS SSV/AP-0A SSV/AP-0A - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

SSV/AP-0A MICRO DETECTORS Photoelectric sensor Receiver 3 m NO/PNP cable 2m plastic

Reference: SSV/AP-0A

Manufacturer: MICRO DETECTORS

Description:

Photoelectric sensor Receiver 3 m NO/PNP cable 2m plastic
SSV/AP-0A Photoelectric sensor Receiver 3 m NO/PNP cable 2m plast.

Categories:

  • MICRO DETECTORS > Encoders

Brand new product in its original packaging covered by the warranties and certifications provided by MICRO DETECTORS

  • More Info
  • Reviews
Guarantee, repair and return.

Unit Price: 50,33 €

This price is per unit and is the net value (not including taxes if applicable).

Calculate price by quantity

QuantityPrice

Standard lead time: 4-6 weeks.

  • These delivery times are an estimate any may vary when the item order has been processed.

LAST VIEWED

MORE INFO

Technical features

Nominal sensing distance3m
Thermal drift of Sr≤10% Sr
Repeat Accuracy5%
minimum detectable objectØ 1mm
Sensitivity adjustmentNo

Application

Function PrincipleThrough beam
Emitter/ReceiverReceiver
Optic positionAxial

Outputs

Output typePNP
Output FunctionNO
Switching frequency250Hz

Electrical data

Operating Voltage10-30Vdc
No-Load supply current≤20mA
Load current≤100mA
Leakage current≤10μA
Output voltage drop2,5V max. IL =100 mA
Max ripple content10%
LED indicatorsYellow (output state)
Time delay before availability≤200ms
Short-circuit protectionYes
Reverse Polarity ProtectionYes
EmissionRed (660nm)
Interference to external light5000lux (incandescent lamp), 10000lux (sunlight)
Impulsive Overvoltage ProtectionYes

Mechanical data

DimensionsM18 x 1/L=63,9mm
Weight70g
Housing MaterialPBT
Connections2m PVC cable
Active Head MaterialPMMA
Tightening torque1Nm
Operating temperature- 25°C…+ 70° C (Without freeze)

Test/Approvals

ApprovalsCE, cULus
EMC compatibilityEN 60947-5-2
Shocks and vibrationsVibration IEC 60068-2-6 / Shock IEC 60068-2-27
Degree of protectionIP67

Accessories

Supplied Accessoriesnuts M18 x 1

Electrical diagrams of the connections


Dimension (mm)
