SSH/00-0E MICRO DETECTORS Photoelectric sensor Emitter 14 m plastic plug M12
SSH/00-0E
MICRO DETECTORS
Photoelectric sensor Emitter 14 m plastic plug M12
SSH/00-0E Photoelectric sensor Emitt. 14 m plast. conn. M12
Encoders
Brand new product in its original packaging covered by the warranties and certifications provided by MICRO DETECTORS
Often bought together
▲Best sellers
▲More info
▲Technical features
| Nominal sensing distance | 14m | |
| Thermal drift of Sr | ≤10% Sr | |
Application
| Function Principle | Through beam | |
| Emitter/Receiver | Emitter | |
| Optic position | Axial | |
Electrical data
| Operating Voltage | 10-30Vdc | |
| No-Load supply current | ≤40mA | |
| Max ripple content | 10% | |
| LED indicators | Green (powerON) | |
| Time delay before availability | ≤200ms | |
| Reverse Polarity Protection | Yes | |
| Emission | Infrared (880nm) | |
| Impulsive Overvoltage Protection | Yes | |
Mechanical data
| Dimensions | M18 x 1 /L =78mm | |
| Weight | 30g | |
| Housing Material | PBT | |
| Connections | M12 4pin Plug | |
| Active Head Material | PMMA | |
| Tightening torque | 1Nm | |
| Operating temperature | - 25°C…+ 70° C (Without freeze) | |
Test/Approvals
| Approvals | CE, cULus | |
| EMC compatibility | EN 60947-5-2 | |
| Shocks and vibrations | Vibration IEC 60068-2-6 / Shock IEC 60068-2-27 | |
| Degree of protection | IP67 | |
Accessories
| Supplied Accessories | nuts M18 x 1 | |
Electrical diagrams of the connections
Connector
Dimension (mm)
Response curves
Dimensione Spot
Disassamento Parallelo
Eccesso di Guadagno
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE MICRODETECTORS EN.pdf | 79 Mbytes |
|
| Download general catalog |
|
