SPU/00-0E MICRO DETECTORS Photoelectric sensor Emitter RED emission narrow beam
SPU/00-0E
MICRO DETECTORS
Photoelectric sensor Emitter RED emission narrow beam
SPU/00-0E Photoelectric sensor Emitt. RED emission narrow beam
Encoders
Brand new product in its original packaging covered by the warranties and certifications provided by MICRO DETECTORS
Best sellers
▲More info
▲Technical details
Discovery properties
| Nominal range | 3m (SSU), 8m (SSG) | |
| Thermal drift | ≤10% Sr | |
Applications
| Principle of operation | Barrier | |
| Transmitter/Receiver | Issuer | |
| Position lens | Radial (90°) | |
Electrical data
| Supply voltage | 10-30Vdc | |
| Absorption of current in the vacuum | ≤25mA | |
| Maximum residual ripple | 10% | |
| LED indicators | Yellow (access) | |
| Delay to the availability | ≤200ms | |
| Protection polarity reversal | Yes | |
| Emission | Red light (660nm) | |
| Protection against impulse overvoltage | Yes | |
Mechanical data
| Dimensions | M18 x 1 /L =75,7 mm | |
| Weight | 30g | |
| body material | PBT | |
| Connections | Output connector M12 4 pins | |
| Material of the active surface | PMMA | |
| Tightening torque | 1Nm | |
| Operating temperature | - 25°C...+ 70° C (without condensation) | |
Test/Certifications
| Certifications | CE, cULus | |
| Electromagnetic compatibility | According to en 60947-5-2 | |
| Shock and vibration | Vibration IEC 60068-2-6 / Shock IEC 60068-2-27 | |
| Degree of protection | IP67 | |
Accessories
| Accessories included | 1 x nut M18 | |
Electrical wiring diagram of the connections
Connector
Dimension (mm)
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE MICRODETECTORS EN.pdf | 79 Mbytes |
|
| Download general catalog |
|
