RXC/00-3B MICRO DETECTORS Photoelectric sensor Retroreflective 12 m AC. Relay with fixing slide plug M12
RXC/00-3B
MICRO DETECTORS
Photoelectric sensor Retroreflective 12 m AC. Relay with fixing slide plug M12
RXC/00-3B Photoelectric sensor Retroreflective 12 m AC. Relay with fixing slide conn. M12
Encoders
Brand new product in its original packaging covered by the warranties and certifications provided by MICRO DETECTORS
Often bought together
▲Best sellers
▲More info
▲Technical details
Discovery properties
| Nominal range | 12m | |
| Thermal drift | 10% Sr | |
| Repeatability | 5% | |
| Sensitivity adjustment | Singolo giro potenziometro | |
Applications
| Principle of operation | Retroriflessione | |
| Position lens | Assiale | |
Outputs
| Output type | Relay | |
| Switching frequency | 25Hz | |
Electrical data
| Supply voltage | 20-253 vac/ 20-60Hz | |
| Absorption of current in the vacuum | 25mARMS | |
| Load current | 3A-250Vac/3A-30Vdc (750VA/90W) | |
| LED indicators | Rosso debole (output), rosso intense ( allineamento), green ( segnale stabile) | |
| Delay to the availability | 100ms | |
| Protection polarity reversal | Yes | |
| Emission | Led Infrarosso | |
| Immunity to ambient light | ≥ 10000lux (lamp incandesente) | |
| Protection against impulse overvoltage | Yes | |
Mechanical data
| Dimensions | 26x86,6x61 | |
| Weight | 90g | |
| Connections | Uscita connettore M12 | |
| Operating temperature | - 25°C...+ 70°C ( without condense) | |
Test/Certifications
| Certifications | EC | |
| Electromagnetic compatibility | According to en 60947-5-2 | |
| Shock and vibration | Vibrazioni IEC 60068-2-6 / Urti IEC 60068-2-27 | |
| Degree of protection | IP65 | |
Accessories
| Accessories included | ST80 staffa di montaggio e cacciavite | |
Electrical wiring diagram of the connections
Connector
Dimension (mm)
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE MICRODETECTORS EN.pdf | 79 Mbytes |
|
| Download general catalog |
|
