MICRO DETECTORSEncodersQX3/A0-2E MICRO DETECTORS Photoelectric sensor diffuse 300 mm 90° optic plug M12
MICRO DETECTORS QX3/A0-2E QX3/A0-2E - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

QX3/A0-2E MICRO DETECTORS Photoelectric sensor diffuse 300 mm 90° optic plug M12

Reference: QX3/A0-2E

Manufacturer: MICRO DETECTORS

Description:

Photoelectric sensor diffuse 300 mm 90° optic plug M12
QX3/A0-2E Photoelectric sensor Diffuse 300 mm 90° optic conn. M12

Categories:

  • MICRO DETECTORS > Encoders

Brand new product in its original packaging covered by the warranties and certifications provided by MICRO DETECTORS

  • More Info
  • Reviews
Guarantee, repair and return.

Unit Price: 118,74 €

This price is per unit and is the net value (not including taxes if applicable).

Calculate price by quantity

QuantityPrice

Standard lead time: 4-6 weeks.

  • These delivery times are an estimate any may vary when the item order has been processed.

MORE INFO

Technical features

Nominal sensing distance300mm
Repeat Accuracy≤ 5%
Sensitivity adjustment1 turn trimmer

Application

Function PrincipleDiffuse reflection
Optic positionRight angle

Outputs

Output typePNP/NPN
Output FunctionNO
Switching frequency750Hz

Electrical data

Operating Voltage10,8-30Vdc
No-Load supply current20mA max
Load current≤ 300mA
Leakage current≤ 100μA @ 30Vdc
Output voltage drop1,2V max
Max ripple content≤ 10%
Time delay before availability200ms
Short-circuit protectionYes
Reverse Polarity ProtectionYes
Emissioninfrared (880nm)
Interference to external light3000lux Incandescent Lamp, 10000lux

Mechanical data

Dimensions15x23x44
Weight70g
ConnectionsM12 plug
Active Head MaterialAcrylic
Operating temperature- 25°C…+ 70°C ( without freeze)
MaterialABS

Test/Approvals

ApprovalsCE
EMC compatibilityEN 60947-5-2
Shocks and vibrationsVibration IEC 60068-2-6 / Shock IEC 60068-2-28
Degree of protectionIP65

Accessories

Supplied AccessoriesST70 mounting brakets and screws

Electrical diagrams of the connections


Connector


Dimension (mm)



Response curves

Dimensione Spot


Disassamento Parallelo


Eccesso di Guadagno
