QX3/A0-1A MICRO DETECTORS Photoelectric sensor diffuse 300 mm axial optic cable 2m
QX3/A0-1A
MICRO DETECTORS
Photoelectric sensor diffuse 300 mm axial optic cable 2m
Encoders
Brand new product in its original packaging covered by the warranties and certifications provided by MICRO DETECTORS
Best sellers
▲More info
▲Technical features
| Nominal sensing distance | 300mm | |
| Repeat Accuracy | ≤ 5% | |
| Sensitivity adjustment | 1 turn trimmer | |
Application
| Function Principle | Diffuse reflection | |
| Optic position | Axial | |
Outputs
| Output type | PNP/NPN | |
| Output Function | NO | |
| Switching frequency | 750Hz | |
Electrical data
| Operating Voltage | 10,8-30Vdc | |
| No-Load supply current | 20mA max | |
| Load current | ≤ 300mA | |
| Leakage current | ≤ 100μA @ 30Vdc | |
| Output voltage drop | 1,2V max | |
| Max ripple content | ≤ 10% | |
| Time delay before availability | 200ms | |
| Short-circuit protection | Yes | |
| Reverse Polarity Protection | Yes | |
| Emission | infrared (880nm) | |
| Interference to external light | 3000lux Incandescent Lamp, 10000lux | |
Mechanical data
| Dimensions | 15x23x40 | |
| Weight | 70g | |
| Connections | 2m PVC cable | |
| Active Head Material | Acrylic | |
| Operating temperature | - 25°C…+ 70°C ( without freeze) | |
| Material | ABS | |
Test/Approvals
| Approvals | CE | |
| EMC compatibility | EN 60947-5-2 | |
| Shocks and vibrations | Vibration IEC 60068-2-6 / Shock IEC 60068-2-28 | |
| Degree of protection | IP65 | |
Accessories
| Supplied Accessories | ST70 mounting brakets and screws | |
Electrical diagrams of the connections
Dimension (mm)
Response curves
Dimensione Spot
Disassamento Parallelo
Eccesso di Guadagno
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE MICRODETECTORS EN.pdf | 79 Mbytes |
|
| Download general catalog |
|
