MICRO DETECTORS MVE/00-0E MVE/00-0E - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

MVE/00-0E MICRO DETECTORS Photoelectric sensor Emitter plastic plug M12

Reference: MVE/00-0E

Manufacturer: MICRO DETECTORS

Description:

Photoelectric sensor Emitter plastic plug M12
MVE/00-0E Photoelectric sensor Emitt. plast. conn. M12

Categories:

  • MICRO DETECTORS > Encoders

Brand new product in its original packaging covered by the warranties and certifications provided by MICRO DETECTORS

  • More Info
  • Reviews
Guarantee, repair and return.

Unit Price: 59,23 €

This price is per unit and is the net value (not including taxes if applicable).

Calculate price by quantity

QuantityPrice

Standard lead time: 4-6 weeks.

  • These delivery times are an estimate any may vary when the item order has been processed.

MORE INFO

Technical details

Discovery properties

Thermal drift≤10%Sr
Repeatability5%
Sensitivity adjustmentNot

Applications

Principle of operationBarrier
Transmitter/ReceiverIssuer
Position lensAxial

Outputs

Output typeTRIAC
Exit functionNC

Electrical data

Supply voltage20...253Vca/50...60Hz
Absorption of current in the vacuum≤30mARMS
Load current5...300mARMS
Leakage current6A
Voltage drop to the output≤3V IL=300mA
Maximum residual ripple≤ 10%
LED indicatorsRed
Delay to the availability200ms
EmissionInfrared (880nm)
Immunity to ambient lightTo 3,000 lux (incandescent lamp), 10,000 lux (sunlight)

Mechanical data

DimensionsM18x1/L=78,9 mm
Weight30g
body materialPBT
ConnectionsOutput connector M12
Material of the active surfacePMMA
Tightening torque1Nm
Operating temperature- 25°C...+ 60° C (without condensation)

Test/Certifications

CertificationsCE, cRUus
Electromagnetic compatibilityAccording to en 60947-5-2
Shock and vibrationVibration IEC 60068-2-6 / Shock IEC 60068-2-27
Degree of protectionIP67

Accessories

Accessories includedNuts metal (2x)

Electrical wiring diagram of the connections


Connector


Dimension (mm)
