MV6/A0-0A MICRO DETECTORS Photoelectric sensor diffuse 400 mm plastic cable 2m axial
MV6/A0-0A
MICRO DETECTORS
Photoelectric sensor diffuse 400 mm plastic cable 2m axial
MV6/A0-0A Photoelectric sensor Diffuse 400 mm plast. cable 2m axial
Encoders
* Brand new product in its original packaging covered by the warranties and certifications provided by MICRO DETECTORS
Best sellers
▲More info
▲Technical features
| Nominal sensing distance | 400mm | |
| Thermal drift of Sr | ≤10%Sr | |
| Repeat Accuracy | 5% | |
| Sensitivity adjustment | No | |
Application
| Function Principle | Diffuse reflection | |
| Notes | With 200x200mm white matt paper | |
| Optic position | Axial | |
Outputs
| Output type | TRIAC | |
| Output Function | NO | |
| Switching frequency | 25Hz | |
Electrical data
| Operating Voltage | 20…253Vac/50…60Hz | |
| No-Load supply current | ≤30mARMS | |
| Load current | 5…300mARMS | |
| Leakage current | 6A | |
| Output voltage drop | ≤3V IL=300mA | |
| Max ripple content | ≤ 10% | |
| LED indicators | Red | |
| Time delay before availability | 200ms | |
| Emission | Infrared (880nm) | |
| Interference to external light | 3.000lux (incandescent lamp), 10.000lux (sunlight) | |
Mechanical data
| Dimensions | M18x1/L=78,9mm | |
| Weight | 100g | |
| Housing Material | PBT | |
| Connections | Cable 2m PVC | |
| Active Head Material | PMMA | |
| Tightening torque | 1Nm | |
| Operating temperature | - 25°C…+ 70° C (without freeze) | |
Test/Approvals
| Approvals | CE, cRUus | |
| EMC compatibility | EN 60947-5-2 | |
| Shocks and vibrations | Vibration IEC 60068-2-6 / Shock IEC 60068-2-27 | |
| Degree of protection | IP67 | |
Accessories
| Supplied Accessories | Metallic nut (2x) | |
Electrical diagrams of the connections
Dimension (mm)
Response curves
Dimensione Spot
Disassamento Parallelo
Eccesso di Guadagno
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE MICRODETECTORS EN.pdf | 4 Mbytes |
|
| Download general catalog |
|
