MICRO DETECTORSEncodersMSE/00-0E MICRO DETECTORS Photoelectric sensor Emitter plastic M12 plug M12
MICRO DETECTORS MSE/00-0E MSE/00-0E - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

MSE/00-0E MICRO DETECTORS Photoelectric sensor Emitter plastic M12 plug M12

Reference: MSE/00-0E

Manufacturer: MICRO DETECTORS

Description:

Photoelectric sensor Emitter plastic M12 plug M12
MSE/00-0E Photoelectric sensor Emitt. plast. M12 conn. M12

Categories:

  • MICRO DETECTORS > Encoders

Brand new product in its original packaging covered by the warranties and certifications provided by MICRO DETECTORS

  • More Info
  • Reviews
Guarantee, repair and return.

Unit Price: 49,13 €

This price is per unit and is the net value (not including taxes if applicable).

Calculate price by quantity

QuantityPrice

Standard lead time: 4-6 days.

  • These delivery times are an estimate any may vary when the item order has been processed.

LAST VIEWED

MORE INFO

Technical details

Discovery properties

Nominal range16m (MSR), 32m (MSD)
Thermal drift≤10% Sr
Repeatability5%
Sensitivity adjustmentNot

Applications

Principle of operationBarrier
Transmitter/ReceiverIssuer
Position lensAxial

Electrical data

Supply voltage10-30Vdc
Absorption of current in the vacuum≤15mA
Maximum residual ripple10%
LED indicatorsYellow (power)
Delay to the availability≤200ms
Protection short circuitShort circuit (auto reset), overvoltage
EmissionInfrared (880 nm)
Immunity to ambient light3000lux (incandescent lamp), 10000lux (sunlight)
Protection against impulse overvoltageProtection impulses surge

Mechanical data

DimensionsM18 x 1 /L =93mm
Weight30g
body materialPBT
ConnectionsConnector M12 4 pins
Material of the active surfacePMMA
Tightening torque1Nm
Operating temperature25°C..+ 70° C (without condensation)

Test/Certifications

CertificationsCE cURus
Electromagnetic compatibilityAccording to en 60947-5-2
Shock and vibrationVibration IEC 60068-2-6 / Shock IEC 60068-2-27
Degree of protectionIP67

Accessories

Accessories includedNut M18 x 1

Electrical wiring diagram of the connections


Connector


Dimension (mm)
