MICRO DETECTORSEncodersMS2/00-0K MICRO DETECTORS Photoelectric sensor diffuse 100 mm plastic plug M12 90°
MICRO DETECTORS MS2/00-0K MS2/00-0K - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

MS2/00-0K MICRO DETECTORS Photoelectric sensor diffuse 100 mm plastic plug M12 90°

Reference: MS2/00-0K

Manufacturer: MICRO DETECTORS

Description:

Photoelectric sensor diffuse 100 mm plastic plug M12 90°
MS2/00-0K Photoelectric sensor Diffuse 100 mm plast. conn. M12 90°

Categories:

  • MICRO DETECTORS > Encoders

Brand new product in its original packaging covered by the warranties and certifications provided by MICRO DETECTORS

  • More Info
  • Reviews
Guarantee, repair and return.

Unit Price: 71,01 €

This price is per unit and is the net value (not including taxes if applicable).

Calculate price by quantity

QuantityPrice

Standard lead time: 4-6 weeks.

  • These delivery times are an estimate any may vary when the item order has been processed.

MORE INFO

Technical features

Resolutionda 100 a 2500 ppr
counting directionA leads B clockwise (shaft view)

Application

max output frequency220 kHz

Outputs

Output typepush-pull / line driver

Electrical data

Operating Voltage5/30 = 4,5 ... 30 V DC (reverse polarity protection)
No-Load supply current800 mW
max load current20 mA / channel

Mechanical data

Weight150 g
Housing MaterialPA66 glass fiber reinforced
Operating temperature-20° ... +70°C
Storage temperature-25° ... +70°C
max shaft load5 N assiale / radiale
Shaft diameterø 6* / 8* / 10 mm
max rotation speed3000 rpm
moment of inertia0,8 x 10-6 kgm2
starting torque at 20°c< 0,01 Nm (IP 64) < 0,06 Nm (IP 65)
shaft material1.4305 / AISI 303 stainless steel
bearings2 ball bearings
bearings life109 revolutions

Test/Approvals

EMC compatibilityIEC 61000-6-2 IEC 61000-6-4
Shocks and vibrations10 G, 10 ... 2000 Hz (IEC 60068-2-6)
Degree of protectionIP 64 (IEC 60529) IP 65 (IEC 60529)

Dimension (mm)
