MICRO DETECTORS MPR/00-1H MPR/00-1H - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

MPR/00-1H MICRO DETECTORS Photoelectric sensor Receiver 16 m metal plug M12

Reference: MPR/00-1H

Manufacturer: MICRO DETECTORS

Description:

Photoelectric sensor Receiver 16 m metal plug M12
Photoelectric sensor Receiver 16 m metal conn. M12

Categories:

  • MICRO DETECTORS > Encoders

Brand new product in its original packaging covered by the warranties and certifications provided by MICRO DETECTORS

  • More Info
  • Reviews
Guarantee, repair and return.

* This article may be obsolete. Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.

Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.

LAST VIEWED

MORE INFO

Technical details

Discovery properties

resolutionof 100 to 2500 ppr
address countIn anticipation of B with clockwise rotation (viewed from side axis)

Applications

max output frequency220 kHz

Outputs

Output typepush-pull / line driver

Electrical data

Supply voltage5/30 = 4,5 ... 30 V DC (protected investment)
Absorption of current in the vacuum800 mW
max load current20 mA per channel

Mechanical data

Weight150 g
body materialaluminium varnished
Operating temperature-20° ... +70°C
Storage temperature-25° ... +70°C
max shaft load5 N axial / radial
diameter shaftø 6* / 8* / 10 mm
max rotation speed3000 rpm
moment of inertia0.8 x 10-6 kgm2
starting torque at 20°c< 0.01 Nm (IP 64) < 0.06 Nm (IP 65)
shaft materialstainless steel 1.4305 / AISI 303
bearings2 ball bearings
life bearings109 revolutions

Test/Certifications

Electromagnetic compatibilityIEC 61000-6-2 IEC 61000-6-4
Shock and vibration10 G, 10 ... 2000 Hz (IEC 60068-2-6)
Degree of protectionIP 64 (IEC 60529) IP 65 (IEC 60529)

Dimension (mm)
