MDI58C 892
MDI58C1250S5/30L6SXPA
MICRO DETECTORS
1
Incremental Encoder Solid Shaft 58mm, Flange C, Resolution 1250 ppm, Without Zero Pulse, Line Driver, Shaft 6mm, IP66, Axial Cable 1,5 mt Exit
MDI58C1250S5/30L6SXPA - Solid Shaft 58mm, Flange C, Res. 1250 ppm, Without Zero Pulse, Line Driver, Shaft 6mm, IP66, Axial Cable 1,5 mt Exit
Sensors
* Brand new product in its original packaging covered by the warranties and certifications provided by MICRO DETECTORS
Thank you for your interest in our products; we hope the delivery time indicated is to your convenience.
While the order is being processed you can select the type of shipment that best suits your needs: 24-hour air express, standard 48-72 hour land, etc.
Resolution | da 100 a 2500 ppr | |
counting direction | A leads B clockwise (shaft view) |
max output frequency | 220 kHz |
Output type | push-pull / line driver |
Operating Voltage | 5/30 = 4,5 ... 30 V DC (reverse polarity protection) | |
No-Load supply current | 800 mW | |
max load current | 20 mA / channel |
Weight | 150 g | |
Housing Material | PA66 glass fiber reinforced | |
Operating temperature | -20° ... +70°C | |
Storage temperature | -25° ... +70°C | |
max shaft load | 5 N assiale / radiale | |
Shaft diameter | ø 6* / 8* / 10 mm | |
max rotation speed | 3000 rpm | |
moment of inertia | 0,8 x 10-6 kgm2 | |
starting torque at 20°c | < 0,01 Nm (IP 64) < 0,06 Nm (IP 65) | |
shaft material | 1.4305 / AISI 303 stainless steel | |
bearings | 2 ball bearings | |
bearings life | 109 revolutions |
EMC compatibility | IEC 61000-6-2 IEC 61000-6-4 | |
Shocks and vibrations | 10 G, 10 ... 2000 Hz (IEC 60068-2-6) | |
Degree of protection | IP 64 (IEC 60529) IP 65 (IEC 60529) |
Title: | Size: | Type: |
---|---|---|
PDF CATALOGUE MICRODETECTORS EN.pdf | 4 Mbytes | |
Download general catalog |
