MDI58C 268 MDI58C900S5/30L6XXPR MICRO DETECTORS Incremental Encoder Solid Shaft 58mm, Flange C, Resolution 9..
Reference: MDI58C 268
Catalog Number: MDI58C900S5/30L6XXPR
Manufacturer: MICRO DETECTORS
Description:
Incremental Encoder Solid Shaft 58mm, Flange C, Resolution 900 ppm, Without Zero Pulse, Line Driver, Shaft 6mm, IP54, Radial Cable 1,5 mt Exit
MDI58C900S5/30L6XXPR - Solid Shaft 58mm, Flange C, Res. 900 ppm, Without Zero Pulse, Line Driver, Shaft 6mm, IP54, Radial Cable 1,5 mt Exit
Categories:
- MICRO DETECTORS > Sensors
Brand new product in its original packaging covered by the warranties and certifications provided by MICRO DETECTORS
- More Info
- Reviews
* This article may be obsolete. Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.
Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.
LAST VIEWED
MORE INFO
Dettagli tecnici
Proprietà di rilevamento
| Risoluzione | da 100 a 2500 ppr | |
| Direzione di conteggio | A in anticipo su B con rotazione in senso orario (vista lato albero) | |
Applicazione
| Massima frequenza di utilizzo | 220 kHz | |
Uscite
| Tipo di uscita | push-pull / line driver | |
Dati elettrici
| Tensione di alimentazione | 5/30 = 4,5 ... 30 V DC (con protezione inversione) | |
| Assorbimento a vuoto | 800 mW | |
| Massima corrente di carico | 20 mA per canale | |
Dati meccanici
| Peso | 150 g | |
| Materiale corpo | alluminio EN-AW 2011 | |
| Temperatura operativa | -20° ... +70°C | |
| Temperatura di stoccaggio | -25° ... +70°C | |
| Carichi ammessi sull'albero | 5 N assiale / radiale | |
| Diametro albero | ø 6* / 8* / 10 mm | |
| Massima velocità di rotazione | 3000 rpm | |
| Momento d’inerzia | 0,8 x 10-6 kgm2 | |
| Coppia di spunto a 20°C | < 0,01 Nm (IP 64) < 0,06 Nm (IP 65) | |
| Materiale albero | acciaio inox 1.4305 / AISI 303 | |
| Cuscinetti | 2 cuscinetti a sfera | |
| Vita cuscinetti | 109 rivoluzioni | |
Test/Certificazioni
| Compatibilità elettromagnetica | IEC 61000-6-2 IEC 61000-6-4 | |
| Urti e vibrazioni | 50 G, 11 ms (IEC 60068-2-27) - 10 G, 10 ... 2000 Hz (IEC 60068-2-6) | |
| Grado di Protezione | IP 64 (IEC 60529) IP 65 (IEC 60529) | |
Dimensioni (mm)
