MDI58B 2691 MDI58B1440S5/30P10SXM12A.162 MICRO DETECTORS Incremental Encoder Solid Shaft 58mm, Flange B, Res..
MDI58B 2691
MDI58B1440S5/30P10SXM12A.162
MICRO DETECTORS
Incremental Encoder Solid Shaft 58mm, Flange B, Resolution 1440 ppm, Without Zero Pulse, Push-Pull, Shaft 10mm, IP66, Axial M12 Connector Exit
MDI58B1440S5/30P10SXM12A.162 - Solid Shaft 58mm, Flange B, Res. 1440 ppm, Without Zero Pulse, Push-Pull, Shaft 10mm, IP66, Axial M12 Connector Exit
Sensors
* Brand new product in its original packaging covered by the warranties and certifications provided by MICRO DETECTORS
Best sellers
▲More info
▲MDI 58 B / C series
Standard Ø 58 mm encoder series for industrial applications with high mechanical resistance
Requirements:
- 3 channel encoder (A / B / Z) up to 2500 ppr
- Power supply up to +30 VDC with several electronic outputs available
- Up to 220 kHz output frequency
- Cable or connector output
- Solid shaft diameter up to 10 mm
- Mounting by synchronous, clamping flange
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE MICRODETECTORS EN.pdf | 4 Mbytes |
|
| Download general catalog |
|
