DGR/DP-3DEA MICRO DETECTORS Photoelectric sensor Receiver PNP-DOn D10mm clip Val 10…30Vdc cable 7 m
DGR/DP-3DEA
MICRO DETECTORS
Photoelectric sensor Receiver PNP-DOn D10mm clip Val=10…30Vdc cable 7 m
DGR/DP-3DEA Photoelectric sensor Receiver PNP Don D10mm clip Val=10…30Vdc cable 7 m
Encoders
Brand new product in its original packaging covered by the warranties and certifications provided by MICRO DETECTORS
Best sellers
▲More info
▲Technical details
Discovery properties
| Nominal range | 2m (GD=4) | |
| Thermal drift | ≤10%Sr | |
| Sensitivity adjustment | Not | |
Applications
| Principle of operation | Barrier | |
| Transmitter/Receiver | Receiver | |
| Position lens | Axial | |
Outputs
| Output type | PNP | |
| Exit function | DO | |
| Switching frequency | 40Hz | |
Electrical data
| Supply voltage | 10...30vdc | |
| Absorption of current in the vacuum | ≤10mA | |
| Load current | ≤30mA | |
| Leakage current | ≤10µA | |
| Voltage drop to the output | ≤2V IL=30mA | |
| Maximum residual ripple | ≤ 10% | |
| LED indicators | Power | |
| Delay to the availability | ≤ 100ms | |
| Protection short circuit | Yes | |
| Protection polarity reversal | Yes | |
| Immunity to ambient light | 20,000 lux | |
| Protection against impulse overvoltage | Yes | |
Mechanical data
| Dimensions | M10x1/L=41mm | |
| Weight | 210g | |
| body material | PC | |
| Connections | Cable 7m PVC | |
| Material of the active surface | PMMA | |
| Operating temperature | - 25°C...+ 70° C (without condensation) | |
Test/Certifications
| Certifications | EC | |
| Electromagnetic compatibility | IN 60947-5-3 | |
| Shock and vibration | Vibration IEC 60068-2-6 / Shock IEC 60068-2-27 | |
| Degree of protection | IP67 | |
Electrical wiring diagram of the connections
Dimension (mm)
Datasheet - PDF
