CV/CB3-10 MICRO DETECTORS Optical fibre scanner glass sleeve
CV/CB3-10
MICRO DETECTORS
Optical fibre scanner glass sleeve
CV/CB3-10 Optical fibre scanner glass sleeve
Encoders
* Brand new product in its original packaging covered by the warranties and certifications provided by MICRO DETECTORS
Best sellers
▲More info
▲Technical features
| Nominal sensing distance | 0,5…4mm shielded; 0,5…8mm unshielded | |
| Thermal drift of Sr | < 20% | |
| Repeat Accuracy | 5% | |
| Sensitivity adjustment | Yes - auto teach | |
| Hysteresis | ≤ 20% | |
Outputs
| Output type | PNP + NPN | |
| Output Function | NO + NC | |
| Switching frequency | ≤15Hz | |
Electrical data
| Operating Voltage | 10 - 40Vdc | |
| No-Load supply current | ≤12mA | |
| Load current | ≤ 200mA | |
| Leakage current | ≤ 300μA | |
| Output voltage drop | ≤ 2,5V @ IL = 200mA | |
| Max ripple content | ≤10% | |
| LED indicators | Yellow LED (object detected), green LED power supply/stability | |
| Time delay before availability | ≤ 200ms | |
| Short-circuit protection | polarity reversal, overvoltage | |
| Reverse Polarity Protection | Yes | |
| Impulsive Overvoltage Protection | Yes | |
Mechanical data
| Dimensions | M12 x 1 / L = 78mm | |
| Mounting | Shielded/Unshielded | |
| Weight | 110g | |
| Housing Material | thermoplastic polyester | |
| Connections | 2m PVC cable | |
| Active Head Material | thermoplastic polyester | |
| Operating temperature | -35°C…+85°C (without freeze) | |
| Storage temperature | -40°C…+85°C | |
Test/Approvals
| Approvals | CEcULus | |
| EMC compatibility | IEC 60947-5-2 | |
| Shocks and vibrations | Vibration IEC 60068-2-6 / Shock IEC 60068-2-27 | |
| Degree of protection | IP 67 (IEC 60529) NEMA 1,3,4,6,13 | |
Accessories
| Supplied Accessories | 2 x M12 nuts | |
Electrical diagrams of the connections
Dimension (mm)
Response curves
Non schermato
Schermato
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE MICRODETECTORS EN.pdf | 4 Mbytes |
|
| Download general catalog |
|
