MICRO DETECTORSEncodersCQ55/BP-3A MICRO DETECTORS Capacitive sensor cubic Plastic DC 25mm PNP NO+NC cable 2m 90°
MICRO DETECTORS CQ55/BP-3A CQ55/BP-3A - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

CQ55/BP-3A MICRO DETECTORS Capacitive sensor cubic Plastic DC 25mm PNP NO+NC cable 2m 90°

Reference: CQ55/BP-3A

Manufacturer: MICRO DETECTORS

Description:

Capacitive sensor cubic Plastic DC 25mm PNP NO+NC cable 2m 90°
CQ55/BP-3A Capacitive sensor cubic Plastic DC 25mm PNP NO+NC cable 2m 90°

Categories:

  • MICRO DETECTORS > Encoders

Brand new product in its original packaging covered by the warranties and certifications provided by MICRO DETECTORS

  • More Info
  • Reviews
Guarantee, repair and return.

Unit Price: 102,48 €

This price is per unit and is the net value (not including taxes if applicable).

Calculate price by quantity

QuantityPrice

Standard lead time: 4-6 weeks.

  • These delivery times are an estimate any may vary when the item order has been processed.

LAST VIEWED

MORE INFO

Technical features

Nominal sensing distance4…25mm
Thermal drift of Sr< 20%
Repeat Accuracy5%
Sensitivity adjustmentYes
Hysteresis≤ 20%

Outputs

Output typePNP
Output FunctionNO + NC
Switching frequency50Hz

Electrical data

Operating Voltage10-40Vdc
No-Load supply current≤10mA
Load current≤200mA
Leakage current≤ 10µA
Output voltage drop2,5Vmax @IL=200mA
Max ripple content≤10%
LED indicatorsYellow LED (object detected)
Time delay before availability≤100ms
Short-circuit protectionYes, autoreset
Reverse Polarity ProtectionYes
Impulsive Overvoltage ProtectionYes

Mechanical data

Dimensions55x35x15mm
MountingUnshielded
Weight150g
Housing MaterialPC
Connections2m PVC cable
Active Head MaterialPC
Operating temperature-25°C…+80°C (without freeze)
Storage temperature-40°C…+85°C

Test/Approvals

ApprovalsCEcULus
EMC compatibilityIEC 60947-5-2
Degree of protectionIP 67 (EN60529) NEMA 1,3,4,6,13

Accessories

Supplied Accessoriesscrew driver

Electrical diagrams of the connections


Dimension (mm)
