CL08/1B-00A MICRO DETECTORS Connector plug M8 female 4 poles Axial a fast connection
CL08/1B-00A
MICRO DETECTORS
Connector plug M8 female 4 poles Axial a fast connection
CL08/1B-00A Connector Conn. M8 female 4 poles Axial a fast connection
Encoders
Brand new product in its original packaging covered by the warranties and certifications provided by MICRO DETECTORS
Best sellers
▲More info
▲Technical features
Application
| Fixing | screw terminals | |
Electrical data
| Rated current | a 40°C 4 A | |
| Wires | 4 | |
| Insulation resistance | ≥ 100 MΩ | |
| Contact resistance | ≤ 5 mΩ | |
| Rated voltage | 60 V (3 plugs) 30 V (4 plugs) | |
Mechanical data
| Connections | a cablaggio rapido | |
| Tightening torque | 0,2 Nm (M8 nut) | |
| Operating temperature | -40 °C ... 85 °C | |
| Plug | M8 | |
| Outer diameter | 3,5 mm ... 5 mm | |
| Head type | Axial | |
| Stripping lenght of the sheath | 12 mm | |
| Gasket material | ≤ 5 mΩ | |
| Wire isolation | ≥ 100 MΩ | |
| Conductors section | 0,14 mm²...0,5 mm² | |
| Model | Female | |
Test/Approvals
| Degree of protection | IP67 | |
Dimension (mm)
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE MICRODETECTORS EN.pdf | 79 Mbytes |
|
| Download general catalog |
|
