C18P/C0-1A MICRO DETECTORS Capacitive sensor M18 Plastic Shielded AC 8mm NC cable 2m axial
C18P/C0-1A
MICRO DETECTORS
Capacitive sensor M18 Plastic Shielded AC 8mm NC cable 2m axial
Encoders
* Brand new product in its original packaging covered by the warranties and certifications provided by MICRO DETECTORS
Best sellers
▲More info
▲Technical features
| Nominal sensing distance | 3…8mm | |
| Thermal drift of Sr | < 20% | |
| Repeat Accuracy | 5% | |
| Sensitivity adjustment | Yes | |
| Hysteresis | ≤ 20% | |
Outputs
| Output type | SCR | |
| Output Function | NC | |
| Switching frequency | 10Hz | |
Electrical data
| Operating Voltage | 20-250Vac | |
| No-Load supply current | ≤12mA | |
| Load current | ≤ 500mA; max 2,5A 20ms | |
| Leakage current | ≤ 100μA | |
| Output voltage drop | ≤ 10VAC @ IL ≥20mA | |
| Max ripple content | ≤10% | |
| LED indicators | Yellow LED (object detected) | |
| Time delay before availability | ≤ 200ms | |
| Short-circuit protection | polarity reversal, overvoltage | |
| Reverse Polarity Protection | Yes | |
| Impulsive Overvoltage Protection | Yes | |
Mechanical data
| Dimensions | M18 x 1 / L = 87mm | |
| Mounting | Shielded | |
| Weight | 150g | |
| Housing Material | thermoplastic polyester | |
| Connections | 2m PVC cable | |
| Active Head Material | thermoplastic polyester | |
| Tightening torque | 2,6Nm | |
| Operating temperature | -35°C…+85°C (ohne Kondensation) | |
| Storage temperature | -40°C…+85°C | |
Test/Approvals
| Approvals | CEcULus | |
| EMC compatibility | IEC 60947-5-2 | |
| Shocks and vibrations | Vibration IEC 60068-2-6 / Shock IEC 60068-2-27 | |
| Degree of protection | IP 67 - IP68 (60min) - IP69K - NEMA 1, 2, 4, 4x, 5, 6, 6p, 12 | |
Accessories
| Supplied Accessories | screw driver, 2 x M18 nuts | |
Electrical diagrams of the connections
Dimension (mm)
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE MICRODETECTORS EN.pdf | 4 Mbytes |
|
| Download general catalog |
|
