BS4/00-0C MICRO DETECTORS Photoelectric sensor diffuse 200 mm cable 2m 90°
BS4/00-0C
MICRO DETECTORS
Photoelectric sensor diffuse 200 mm cable 2m 90°
BS4/00-0C Photoelectric sensor Diffuse 200 mm cable 2m 90°
Encoders
Brand new product in its original packaging covered by the warranties and certifications provided by MICRO DETECTORS
Best sellers
▲More info
▲Technical features
| Nominal sensing distance | 200mm | |
| Repeat Accuracy | ≤ 5% | |
| Sensitivity adjustment | 1 turn trimmer | |
Application
| Function Principle | Diffuse reflection | |
| Optic position | Axial | |
Outputs
| Output type | DECOUT (PNP, NPN, NO, NC selectable) | |
| Output Function | NO, NC selectable | |
| Switching frequency | 80Hz | |
Electrical data
| Operating Voltage | 10-30Vdc | |
| No-Load supply current | 25mA max | |
| Load current | 100mA | |
| Leakage current | ≤ 10μA | |
| Output voltage drop | 1,2V max | |
| Max ripple content | ≤ 10% | |
| LED indicators | Red ( output energized) | |
| Time delay before availability | 200ms | |
| Short-circuit protection | Yes | |
| Reverse Polarity Protection | Yes | |
| Emission | Infrared (880nm) | |
| Interference to external light | 3000lux Incandescent Lamp, 10000lux | |
Mechanical data
| Dimensions | 16x37x64 | |
| Weight | 185g | |
| Connections | Right angle cable exit | |
| Active Head Material | PMMA | |
| Operating temperature | - 25°C…+ 70°C ( without freeze) | |
| Material | ABS | |
Test/Approvals
| Approvals | CE | |
| EMC compatibility | EN 60947-5-2 | |
| Shocks and vibrations | Vibration IEC 60068-2-6 / Shock IEC 60068-2-31 | |
| Degree of protection | IP65 | |
Accessories
| Supplied Accessories | ST01 mounting brakets and screws | |
Electrical diagrams of the connections
Dimension (mm)
Response curves
Dimensione Spot
Disassamento Parallelo
Eccesso di Guadagno
