AM1/AP-3H7F
MICRO DETECTORS
1
Inductive sensor M12 shielded NO/PNP housing 70mm plug M12
AM1/AP-3H7F Inductive sensor M12 shielded NO/PNP housing 70mm conn. M12
Encoders
* Brand new product in its original packaging covered by the warranties and certifications provided by MICRO DETECTORS
Thank you for your interest in our products; we hope the delivery time indicated is to your convenience.
While the order is being processed you can select the type of shipment that best suits your needs: 24-hour air express, standard 48-72 hour land, etc.
Nominal range | 0.6 mm | |
Operating range | 0...0,48 mm | |
Object reference | 4x4mm FE360 | |
Correction Factor | copper: 0,32 ± 10% / aluminum: 0,24 ± 10% / brass: 0,39 ± 10% / stainless Steel: 0,57 ± 10% | |
Thermal drift | < 10% | |
Repeatability | 5% (UB 24V Ta=23°C ±5°C) | |
Hysteresis | 1 ... 20% |
Output type | NPN | |
Exit function | NOT | |
Switching frequency | 3kHz |
Supply voltage | 10 - 30vdc | |
Absorption of current in the vacuum | ≤ 10mA | |
Load current | ≤ 100mA | |
Leakage current | ≤ 10µA | |
Voltage drop to the output | ≤ 1.5 V @100mA | |
Maximum residual ripple | ≤10% | |
LED indicators | Yellow LED output status | |
Delay to the availability | ≤ 50ms | |
Protection short circuit | Yes | |
Protection polarity reversal | Yes | |
Protection against inductive loads | Yes |
Dimensions | Ø3 / L = 22mm | |
Mounting | Flush | |
Weight | 30g | |
body material | Stainless steel AISI303 | |
Connections | Cable PUR 2m | |
Material of the active surface | PBT | |
Operating temperature | -25°C...+70°C |
Certifications | CEUL | |
Electromagnetic compatibility | IEC 60947-5-2 | |
Shock and vibration | Vibration IEC 60068-2-6 / Shock IEC 60068-2-27 | |
Degree of protection | IP 67 (EN60529) |
Title: | Size: | Type: |
---|---|---|
PDF CATALOGUE MICRODETECTORS EN.pdf | 4 Mbytes | |
Download general catalog |
