AK1/A0-2A8R
MICRO DETECTORS
1
Inductive sensor M18 unshielded NO cable 10m axial
AK1/A0-2A8R Inductive sensor M18 unshielded NO cable 10m axial
Encoders
* Brand new product in its original packaging covered by the warranties and certifications provided by MICRO DETECTORS
Thank you for your interest in our products; we hope the delivery time indicated is to your convenience.
While the order is being processed you can select the type of shipment that best suits your needs: 24-hour air express, standard 48-72 hour land, etc.
Nominal sensing distance | 0,6mm | |
Operanting distance | 0…0,48mm | |
Standard target | 4x4mm FE360 | |
Correction Factor | copper: 0,32 ± 10% / aluminium: 0,24 ± 10% / brass: 0,39 ± 10% / stainless steel: 0,57 ± 10% | |
Thermal drift of Sr | < 10% | |
Repeat Accuracy | 5% (UB 24V Ta=23°C ±5°C) | |
Hysteresis | 1 … 20% |
Output type | NPN | |
Output Function | NO | |
Switching frequency | 3kHz |
Operating Voltage | 10 - 30Vdc | |
No-Load supply current | ≤ 10mA | |
Load current | ≤ 100mA | |
Leakage current | ≤ 10μA | |
Output voltage drop | ≤ 1,5V @100mA | |
Max ripple content | ≤10% | |
LED indicators | Yellow LED output state | |
Time delay before availability | ≤ 50ms | |
Short-circuit protection | Yes (auto-reset) | |
Reverse Polarity Protection | Yes | |
Protection against inductive loads | Yes |
Dimensions | Ø3 / L = 22mm | |
Mounting | Shielded | |
Weight | 30g | |
Housing Material | AISI303 Stainless Steel | |
Connections | 2m PUR Cable | |
Active Head Material | PBT | |
Operating temperature | -25°C…+70°C |
Approvals | CEUL | |
EMC compatibility | IEC 60947-5-2 | |
Shocks and vibrations | Vibration IEC 60068-2-6 / Shock IEC 60068-2-27 | |
Degree of protection | IP 67 (EN60529) |
