TDR-480-48 MEANWELL AC-DC Industrial 3-phase DIN rail power supply with PFC and Constant Current, Output 48V..
Reference: TDR-480-48
Manufacturer: MEANWELL
Description:
AC-DC Industrial 3-phase DIN rail power supply with PFC and Constant Current, Output 48VDc / 10A
Categories:
- MEANWELL > DIN RAIL > TDR
Brand new product in its original packaging covered by the warranties and certifications provided by MEANWELL
- More Info
- Reviews
MORE INFO
| Name | TDR-480-48 |
|---|---|
| Long Description | Switch mode Power supply three-Phase. Format to install on a Din Rail. Input range three-Phase340-550Vca47-63Hz. Can be run in two phases. Output voltage48vdc.(Adjustable with potentiometer 48-55Vcc). Output intensity:10A.Range of output current 0-10A according to demand load. Power:480W. Factor Corrector, Power>0,86. Alarm output voltage to the correct DC-Ok. Efficiency:93%. Working temperature: from-30up+70ºCof ambient temperature. Consult the technical data sheet to see the curves of drift. Dimensions (Width x Height x depth):85,5 x 125,2 x 128,5 mm 3 years of warranty. Manufacturer: MEANWELL. The series TDR are power supplies DIN rail three-phase, with metallic casing. With wide input range from 340-550Vca have a very compact size, to 85.5 mm for the TDR-480 or so only 110 mm for the TDR-960.Models are with high efficiency of up to 94,5%, and PFC function is active. Can be installed on DIN rail TS-35 / 7,5 or 15. Among its functionalities we have limiting circuit of constant current signal through relay DC OK or function of load distribution in the models of 960W. |
| Country of Origin | Taiwan |
| Manufacturer | MEAN WELL |
| Product type | Power supply AC/DC |
| Format | Din Rail |
| Subformato | Narrow |
| Applications | Industrial, Telecommunications |
| Series | TDR-480 |
| Warranty (Years) | 3,00 |
| Height (mm) | 128.50 |
| Width (mm) | 125.20 |
| Long/Background | 85.50 |
| Type of Entry CA | Three-phase |
| AC input Min | 340,00 |
| AC input Max | 550,00 |
| Input frequency | 50 Hz, 60 Hz |
| Input connector | Screw-Type |
| Output voltage | 48,00 |
| Power (W) | 480,00 |
| Peak Power (W) | Four hundred eighty |
| Output connector | Screw-Type |
| Fan | Yes |
| Alarms | Output OK |
| Isolation (V) | 3.000,00 |
| Approvals | EC, EAC, UL |
