PWM-120-24DA
MEANWELL
1
AC-DC Single output LED driver Constant Voltage (CV), PWM output for LED strips, Output 24VDC / 5A, Dimming with DALI
LED DRIVERS > PWM
* Brand new product in its original packaging covered by the warranties and certifications provided by MEANWELL
Thank you for your interest in our products; we hope the delivery time indicated is to your convenience.
While the order is being processed you can select the type of shipment that best suits your needs: 24-hour air express, standard 48-72 hour land, etc.
Name | PWM-120-24DA |
---|---|
Long Description | LED driver dimmable. Specially designed for the regulation of LED strips. Format in box waterproof plasticIP67. Input range90-305Vca47-63Hz. Output voltage24vdc. Output intensity5A. Range of output current 0-5A according to demand load. Power:120W. Efficiency typical:90%. Regulation DALI0% to 100% of the output intensity. Certificate to DALI. Input class II without grounding. Factor corrector, power>0.96to 230vac at full load. Consumption without load <0.5 W. Operating temperature range of caseTcfrom-40ºCup+90ºC. Dimensions (Length x Width x Height):191 x 63 x 37.5 mm 5 years of warranty. Manufacturer: MEAN WELL. The series PWM are LED Drivers designed to work directly with LED strips. Must be equipment that is fed at constant voltage. The version is compatible with any system DALI. With plastic housing designed for architectural applications, decorative, outdoor or any application of LED lighting need a driver of high quality. Approved HL Class I Division 2 for ex-zones in the US. Compatible with any system DALI. |
Country of Origin | China |
Stock | Yes |
Manufacturer | MEAN WELL |
Product type | LED Driver |
Format | Box |
Subformato | IP67 |
Applications | Lighting |
Series | PWM-120-DA |
State | New |
Warranty (Years) | 5,00 |
Height (mm) | 37.50 |
Width (mm) | 63.00 |
Long/Background | 191.00 |
Type of Entry CA | Single-phase |
AC input Min | 90,00 |
AC input Max | 305,00 |
Input frequency | 50 Hz, 60 Hz |
Input connector | Cable |
Output voltage | 24,00 |
Power (W) | 120,00 |
Peak Power (W) | One hundred twenty |
Dimming | DALI |
Output connector | Cable |
Isolation (V) | 3.750,00 |
Approvals | CCC, CE, ENEC, UL |
