MEANWELLPV40-29B15 MEANWELL DC-DC converter with wide input range.
MEANWELL PV40-29B15 - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

PV40-29B15 MEANWELL DC-DC converter with wide input range.

Code: PV40-29B15

Manufacturer: MEANWELL

Description:

DC-DC converter with wide input range.

Categories:

  • MEANWELL

Brand new product in its original packaging covered by the warranties and certifications provided by MEANWELL

  • More Info
  • Reviews
Guarantee, repair and return.

* This article may be obsolete. Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.

Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.

MORE INFO

Name PV40-29B15
Long Description

Dc/DC converter with wide input range.

Format for mounting on the printed circuit board.

Input range200-1500Vcc.

Output voltage15vdc.

Output intensity2,67 A.

Power:40W.

Isolation input-output 4000Vac 60s.

Efficiency of the82%.

Operation until5000 metersaltitude.

Operating temperature range from-40ºCup+70ºC.(refer to the curve derived in the technical data sheet).

Dimensions (Length x Width x Height):125 x 75 x 40mm.

3 years of warranty.

Manufacturer MORNSUN.

This converter has been designed for photovoltaic applications in solar farms, to feed directly from the panels and provide a stable output and safe for the connected equipment. Are protected against overload and short circuit with auto recovery every 2-15 seconds. Its different protections, high efficiency, insulation, low noise and ripple, making it ideal for multiple applications with great demands.This version is ready to install on the printed circuit board.

Converters with Certificate EN62109 and UL1741/CSA-C22.2 No.107.1
Country of Origin China
Manufacturer MORNSUN
Product type Dc/DC converters
Format For Printed Circuit
Applications Industrial, Solar, Telecommunications
Series PVxx-29Bxx
State Recommended Model
Warranty (Years) 3,00
Height (mm) 40.00
Width (mm) 75.00
Long/Background 125.00
Input range 7.5:1
Range DC Input 200, 360, 1000, 1500
DC input Min 200,00
DC input Max 1.500,00
Input connector Pin
Output voltage 15,00
Power (W) 40,00
Peak Power (W) Forty
Output connector Pin
Isolation (V) 4.000,00
Approvals CE, UL
