PV15-29B05 MEANWELL DC-DC converter with wide input range.
PV15-29B05
MEANWELL
DC-DC converter with wide input range.
Home > MEANWELL
Brand new product in its original packaging covered by the warranties and certifications provided by MEANWELL
Best sellers
▲More info
▲| Name | PV15-29B05 |
|---|---|
| Long Description | Dc/DC converter with wide input range. Format for mounting on the printed circuit board. Input range200-1500Vcc. Output voltage5vdc. Output intensity2A. Power:10W. Isolation input-output 4000Vac 60s. Efficiency of the64%. Operation until5000 metersaltitude. Operating temperature range from-40ºCup+70ºC.(refer to the curve derived in the technical data sheet). Dimensions (Length x Width x Height):125 x 75 x 40mm. 3 years of warranty. Manufacturer MORNSUN. This converter has been designed for photovoltaic applications in solar farms, to feed directly from the panels and provide a stable output and safe for the connected equipment. Are protected against overload and short circuit with auto recovery every 2-15 seconds. Its different protections, high efficiency, insulation, low noise and ripple, making it ideal for multiple applications with great demands.This version is ready to install on the printed circuit board. Converters with Certificate EN62109 and UL1741/CSA-C22.2 No.107.1 |
| Country of Origin | China |
| Manufacturer | MORNSUN |
| Product type | Dc/DC converters |
| Format | For Printed Circuit |
| Applications | Industrial, Solar, Telecommunications |
| Series | PVxx-29Bxx |
| State | Recommended Model |
| Warranty (Years) | 3,00 |
| Height (mm) | 40.00 |
| Width (mm) | 75.00 |
| Long/Background | 125.00 |
| Input range | 7.5:1 |
| Range DC Input | 200, 360, 1000, 1500 |
| DC input Min | 200,00 |
| DC input Max | 1.500,00 |
| Input connector | Pin |
| Output voltage | 5,00 |
| Power (W) | 10,00 |
| Peak Power (W) | Ten |
| Output connector | Pin |
| Isolation (V) | 4.000,00 |
| Approvals | CE, UL |
