ODLC-65-1400DA MEANWELL AC-DC Constant Current mode (CC) LED driver with PFC, Input range 180-295VAC, Output..
ODLC-65-1400DA
MEANWELL
AC-DC Constant Current mode (CC) LED driver with PFC, Input range 180-295VAC, Output 46VDC / 1.4A, Dimming with DALI
LED DRIVERS
* Brand new product in its original packaging covered by the warranties and certifications provided by MEANWELL
Best sellers
▲More info
▲| Name | ODLC-65-1400DA |
|---|---|
| Long Description | LED driver dimmable. Specially designed for powering LEDs directly in a steady stream. Format in box waterproof plasticIP67. Input range180-295Vca47-63Hz. Output in constant current1400mA. Range of output voltage with current mode constant34 to 46Vccaccording to demand load. Power:Of 64.4 W. Efficiency typical:85%. Regulation DALI0% to 100% of the output intensity. Certificate to DALI. Input class II without grounding. Factor corrector, power>0.95to 230vac at full load. Consumption without load <0.5 W. Operating temperature range of caseTcfrom-20ºCup+85ºC. Dimensions (Length x Width x Height):121 x 77 x 28.5 mm 3 years of warranty. Manufacturer: MEAN WELL. The series ODLC are LED drivers designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream. With plastic housing designed for lighting applications in interior. Low ripple current, no flicker (flicker-free). This source works on a Constant Current when we connect the LEDs directly to have a voltage within the Range of Output Voltage mode Constant Current and a working current equal to the output current. Compatible with any system DALI. |
| Country of Origin | China |
| Manufacturer | MEAN WELL |
| Product type | LED Driver |
| Format | Box |
| Subformato | IP67 |
| Applications | Lighting |
| Series | ODLC-65-DA |
| State | New |
| Warranty (Years) | 3,00 |
| Height (mm) | 28.50 |
| Width (mm) | 77.00 |
| Long/Background | 121.00 |
| Type of Entry CA | Single-phase |
| AC input Min | 180,00 |
| AC input Max | 295,00 |
| Input frequency | 50 Hz, 60 Hz |
| Input connector | Cable |
| Intensity of Minimum Output (mA) | 1.400,00 |
| Intensity of Output Maximum (mA) | 1.400,00 |
| Output current mA | One thousand four hundred |
| Power (W) | 64,40 |
| Peak Power (W) | 64.4 |
| Dimming | DALI |
| Output connector | Cable |
| Isolation (V) | 3.750,00 |
| Approvals | CCC, CE, ENEC, UL |
