HEP-185-36A MEANWELL AC-DC Single output industrial power supply with PFC, Output 36VDC / 5.2A, Vo-Io adjust..

Switch-mode power supply for extreme environments.

Format in metal boxIP65.

Input range90-305Vca47-63Hz.

Output voltage36Vcc. Adjustable by potentiometer (33-40Vcc).

Output intensity5.2 To. Range of output current 0-5,2 according To the demand load.

Intensity of maximum output adjustable by potentiometer (2,6-5,2 (A).

Power:187,2 W.

Factor Corrector of a Power >0,95.

Efficiency typical:93,5%.

Working temperature from-55up+70 ° C(refer to the technical sheet to see the curves of drift).

Protection against transients 6KV.

Resistant to vibrations of 10G.

Operating altitude up to 5000 meters.

Dimensions (Length x Width x Height):228 x 68 x 38.8 mm

6 years of warranty.

Manufacturer: MEAN WELL.

The series HEP are sources of industrial power ready to work in extreme environments of dust, moisture, vibration, temperature and altitude. The whole series has a box of sturdy aluminum filled with a special silicone heat-conductive and electrically insulating, and moisture, this allows a better heat dissipation and greater resistance to water. With an innovative design feature with a high efficiency to reduce the power consumption and heat generation. They are ideal for applications where we don't want to use fans and we need a source robust.
