HDR-60-15 MEANWELL AC-DC Ultra slim DIN rail power supply, Input range 85-264VAC, Output 15VDC / 4A, Pass LPS

Switch mode Power supply.

Format to mount on a Din Rail.

Range of universal Input85-264vac47-63Hz.

Output voltage15vdc.Adjustable by potentiometer (13,5-18vdc).

Output intensity4A.

Power:60W.

Efficiency:89%.

Consumption without load<0,3 W.

Working temperature: from-30up+70ºCof ambient temperature. Consult the technical data sheet to see the curves of drift.

Dimensions (Width x Height x depth):52,5 (3SU) x 90 x 54,5 mm

3 years of warranty.

Manufacturer: MEAN WELL.

The series HDR-60 is the latest generation of power supplies for din rail format ladder MEAN WELL.
These sources are class II non-grounded, designed for installation in electrical boxes housing for applications of building automation, industrial applications, security, telecommunications, and also for residential applications to be certified to EN61558-2-16.

Have a low consumption at no load and high efficiency which make it suitable for all types of applications and allow a greater saving of energy.
They are designed to go perfectly in a box electric housing with its format, type ladder and width of 2SU (35mm).

Have protection against short circuits, overloads and over voltages in the output.
