HDR-150-15 MEANWELL AC-DC Ultra slim DIN rail power supply, Input range 85-264VAC, Output 15VDC / 9.5A

Switch mode power supply.

Format to mount on a Din rail.

Range of universal input85-264vac47-63Hz.

Output voltage15vdc.Adjustable by potentiometer (13,5-18vdc.).

Output intensity9,5 A.

Power:142,5 W.

Efficiency typical:89.5 per cent.

LED Indicator of correct operation.

Class ll without the taking of land.

Consumption without load<0,3 W.

Protection against short circuit, over load and over voltage.

Working temperature: from-30up+70 ° Cof ambient temperature. Consult the technical data sheet to see the curves of drift.

Dimensions (Width x Height x depth):105 x 90 x 54,5 mm

3 years of warranty.

Manufacturer: MEAN WELL.

The series HDR-150 is the latest generation of power supplies for din rail format ladder MEAN WELL. These sources are class II non-grounded, designed for installing in an electrical box housing for applications of building automation, industrial applications, security, telecommunications, and also for residential applications to be certified to EN61558-2-16. These sources teinen category III (OVC III) for protection against overvoltages, which allows you to use them in the control boxes without the need of additional protections.

Have a low consumption at no load and high efficiency which make it suitable for all types of applications and allow a greater saving of energy. They are designed to go perfectly in a box electric housing with its format type and ladder width 6SU (105mm).

Have protection against short circuits, overloads and over voltages in the output.
