HDR-100-24N
MEANWELL
1
Available Ship on today
AC-DC Ultra slim DIN rail power supply, Input range 85-264VAC, Output 24VDC / 4.2A, Non-LPS
DIN RAIL
* Brand new product in its original packaging covered by the warranties and certifications provided by MEANWELL
Thank you for your interest in our products; we hope the delivery time indicated is to your convenience.
While the order is being processed you can select the type of shipment that best suits your needs: 24-hour air express, standard 48-72 hour land, etc.
Name | HDR-100-24N |
---|---|
Long Description | Switch mode Power supply. Format to mount on a Din Rail. Range of universal Input85-264vac47-63Hz. Output voltage24vdc.Adjustable by potentiometer (21,6-29Vcc.). Output intensity4,2 A. Power:100,8 W. Efficiency typical:90%. LED Indicator of correct operation. Class ll without the taking of land. Consumption without load<0,3 W. Working temperature: from-30up+70 ° Cof ambient temperature. Consult the technical data sheet to see the curves of drift. Dimensions (Width x Height x depth):70(4SU) x 90 x 54,5 mm 3 years of warranty. Manufacturer: MEAN WELL. The series HDR-100 is the latest generation of power supplies for din rail format ladder MEAN WELL. These sources are class II non-grounded, designed for installing in an electrical box housing for applications of building automation, industrial applications, security, telecommunications, and also for residential applications to be certified to EN61558-2-16. The N version (HDR-100-xx-N) allows us to adjust to a greater range of the output voltage. Have a low consumption at no load and high efficiency which make it suitable for all types of applications and allow a greater saving of energy. They are designed to go perfectly in a box electric housing with its format, type ladder and width of 4SU (54,5 mm). Have protection against short circuits, overloads and over voltages in the output. |
Country of Origin | China |
Stock | Yes |
Manufacturer | MEAN WELL |
Product type | Power supply AC/DC |
Format | Din Rail |
Subformato | Ladder |
Applications | Automation of Buildings, home Appliances, Industrial, Telecommunication |
Series | HDR-100 |
State | Recommended Model |
Warranty (Years) | 3,00 |
Height (mm) | 90.00 |
Width (mm) | 70.00 |
Long/Background | 54.50 |
Type of Entry CA | Single-phase |
AC input Min | 85,00 |
AC input Max | 264,00 |
Input frequency | 50 Hz, 60 Hz |
Input connector | Screw-Type |
Output voltage | 24,00 |
Power (W) | 90,00 |
Peak Power (W) | Ninety |
Output connector | Screw-Type |
Isolation (V) | 3.000,00 |
Approvals | CE, UL |
