HDR-100-24 MEANWELL AC-DC Ultra slim DIN rail power supply, Input range 85-264VAC, Output 24VDC / 3.83A, Pas..

Switch mode Power supply.

Format to mount on a Din Rail.

Range of universal Input85-264vac47-63Hz.

Output voltage24vdc.Adjustable by potentiometer (24-25,5 Vdc.).

Output intensity3,8 A.

Power:92W.

Efficiency typical:90%.

LED Indicator of correct operation.

Class ll without the taking of land.

Consumption without load<0,3 W.

Working temperature: from-30up+70 ° Cof ambient temperature. Consult the technical data sheet to see the curves of drift.

Dimensions (Width x Height x depth):70(4SU) x 90 x 54,5 mm

3 years of warranty.

Manufacturer: MEAN WELL.

The series HDR-100 is the latest generation of power supplies for din rail format ladder MEAN WELL. These sources are class II non-grounded, designed for installing in an electrical box housing for applications of building automation, industrial applications, security, telecommunications, and also for residential applications to be certified to EN61558-2-16.

The N version (HDR-100-xx-N) allows us to adjust to a greater range of the output voltage.

Have a low consumption at no load and high efficiency which make it suitable for all types of applications and allow a greater saving of energy. They are designed to go perfectly in a box electric housing with its format, type ladder and width of 4SU (54,5 mm).

Have protection against short circuits, overloads and over voltages in the output.
