ELP030C0500LS MEANWELL AC-DC Single output LED driver Constant Current (CC), Output 60VDC / 0.5A, IP66, PFC
ELP030C0500LS
MEANWELL
AC-DC Single output LED driver Constant Current (CC), Output 60VDC / 0.5A, IP66, PFC
ADAPTERS > AC plug
Brand new product in its original packaging covered by the warranties and certifications provided by MEANWELL
Best sellers
▲More info
▲| Name | ELP030C0500LS |
|---|---|
| Long Description | LED Driver Constant Current Format, in plastic case, IP20 Input range90-264vac47-63Hz Output in Constant Current500mA Range of Output Voltage with Current mode Constant30 to 60Vccaccording to demand load. Maximum Power:30W Factor Corrector of a Power >is 0.95 Efficiency >88% 5 years warranty The model ELP030C0500LS is a led driver with output in constant current intended to power leds in series to work up to 500mA constant current. It has a range of Universal input of 90 to 264vac which enables it to be used in any country of the world. Connection by terminal block, protection, anti-flip facilitates and secures the installation. It has a high degree of power factor correction as well as a high efficiency which allows to achieve greater energy savings. |
| Country of Origin | China |
| Stock | Yes |
| Manufacturer | EAGLERISE |
| Product type | LED Driver |
| Format | Box |
| Subformato | IP20 |
| Applications | Lighting |
| Series | ELP030C_LS |
| State | High Turnover |
| Warranty (Years) | 5,00 |
| Height (mm) | 34.00 |
| Width (mm) | 45.50 |
| Long/Background | 170.50 |
| Type of Entry CA | Single-phase |
| AC input Min | 90,00 |
| AC input Max | 264,00 |
| Input frequency | 50 Hz, 60 Hz |
| Input connector | Screw-Type |
| Intensity of Minimum Output (mA) | 500,00 |
| Intensity of Output Maximum (mA) | 500,00 |
| Output current mA | Five hundred |
| Power (W) | 30,00 |
| Peak Power (W) | Thirty |
| Output connector | Screw-Type |
| Isolation (V) | 3.750,00 |
| Approvals | EC |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE LED MEANWELL EN.pdf | 7 Mbytes |
|
| PDF CATALOGUE POWER SUPPLY MEANWELL EN.pdf | 9 Mbytes |
|
