EDR-120-48 MEANWELL AC-DC Industrial DIN rail power supply, Output 48V / 2.5A, metal case
EDR-120-48
MEANWELL
AC-DC Industrial DIN rail power supply, Output 48V / 2.5A, metal case
DIN RAIL > EDR
Brand new product in its original packaging covered by the warranties and certifications provided by MEANWELL
Best sellers
▲More info
▲| Name | EDR-120-48 |
|---|---|
| Long Description | Switch mode Power supply. Format for mounting on Din Rail, compact size. Range of universal Input90-264vac47-63Hz. Output voltage48vdc.(Adjustable with potentiometer 48-55Vcc). Output intensity:2.5 To. Power:120W. Efficiency:88.5 per cent. Working temperature: from-20up+60ºCof ambient temperature. Consult the technical data sheet to see the curves of drift. Dimensions (Width x Height x depth):40 x 125,2 x 113,5 mm 2 years of warranty. Manufacturer: MEANWELL. The series RBS are power supplies DIN rail-metal and low-cost. With a wide range of input to have a size quite compact, with a width between 32-40mm, for installation on DIN rail TS-35 / 7,5 or 15. Comply with the rules of conducted emissions EN55022 Class A. |
| Country of Origin | China |
| Manufacturer | MEAN WELL |
| Product type | Power supply AC/DC |
| Format | Din Rail |
| Subformato | Narrow |
| Applications | Industrial, Telecommunications |
| Series | EDR-120 |
| State | Recommended Model |
| Warranty (Years) | 3,00 |
| Height (mm) | 125.20 |
| Width (mm) | 40.00 |
| Long/Background | 113.50 |
| Type of Entry CA | Single-phase |
| AC input Min | 90,00 |
| AC input Max | 264,00 |
| Input frequency | 50 Hz, 60 Hz |
| Input connector | Screw-Type |
| Output voltage | 48,00 |
| Power (W) | 120,00 |
| Peak Power (W) | One hundred twenty |
| Output connector | Screw-Type |
| Fan | Yes |
| Isolation (V) | 3.000,00 |
| Approvals | CE, UL |
