DRS-240-24 MEANWELL UPS with alternating input and continuous output. Output: 24Vdc. 10A. Input: 90-305Vac. ..
DRS-240-24
MEANWELL
UPS with alternating input and continuous output. Output: 24Vdc. 10A. Input: 90-305Vac. Configurable charging. The DRS-240 series are UPSs with AC input and DC output. When there is mains power, the equipment gives a stable output while charging the batteries. In case of power failure, it keeps the output powered from the battery. These power supplies are suitable for security, access control and any application that needs to continue operating even with a power outage. Power: 240W. MODBus.
Home > MEANWELL
Brand new product in its original packaging covered by the warranties and certifications provided by MEANWELL
Best sellers
▲More info
▲| DRS-240 Series | MODEL | OUTPUT VOLTAGE Note.2 | CURRENT RANGE | RIPPLE & NOISE (max.) Note.5 | EFFICIENCY (Typ.) | BATTERY CUT OFF | RECOMMENDED BATTERY CAPACITY(AMP HOURS)Note.3 |
|---|---|---|---|---|---|---|---|
| DRS-240 Series | DRS-240-12 | 12V | 0~20A | 150mVp-p | 90% | Low voltage battery:< 11 0.2V | 20~200AH |
| DRS-240 Series | DRS-240-24 | 24V | 0~10A | 240mVp-p | 92% | Low voltage battery:< 22 0.3V | 10~100AH |
| DRS-240 Series | DRS-240-36 | 36V | 0~6.6A | 360mVp-p | 92% | Low voltage battery:< 33 0.4V | 6.6~66AH |
| DRS-240 Series | DRS-240-48 | 48V | 0~5A | 480mVp-p | 92% | Low voltage battery:< 44 0.5V | 5~50AH |
| OUTPUT | |||||||
| LINE REGULATION | 0.5% 0.5% 0.5% | ||||||
| LOAD REGULATION | 0.5% 0.5% 0.5% | ||||||
| VOLTAGE TOLERANCE Note.6 | 1.0% 1.0% 1.0% | ||||||
| TOTAL OUTPUT POWER Note.4 | 105~135% rated output power | ||||||
| INPUT | |||||||
| VOLTAGE RANGE | 90~127~431VDC 305VAC | ||||||
| FREQUENCY RANGE | 47~63Hz | ||||||
| POWER FACTOR (Typ.) | PF>0.95/230VAC PF>0.98/115VAC at full load | ||||||
| INRUSH CURRENT (Typ.) | COLD START 30A/115VAC 60A/230VAC | ||||||
| AC CURRENT (Typ.) | 2.8A/115VAC 1.4A/230VAC | ||||||
| SETUP / HOLD UP TIME | |||||||
| SETUP, RISE TIME Note.7 | 2400ms, 1000ms/230VAC 2400ms, 1000ms/115VAC at full load | ||||||
| HOLD UP TIME (Typ.) | 16ms/230VAC 10ms/115VAC at full load | ||||||
| PROTECTION | |||||||
| OVERLOAD | Protection type: Constant current limiting, shutdown output voltage after 5 sec. | ||||||
| OVER VOLTAGE | Protection type : Shut down o/p voltage, re-power on to recover | ||||||
| ENVIRONMENT | |||||||
| WORKING SEASON. | -30 ~ +70 (Refer to "Derating Curve") °C | ||||||
| WORKING HUMIDITY | 20~90% RH non-condensing | ||||||
| STORAGE TEMP., HUMIDITY | -40~+85, 10~95% RH non-condensing °C | ||||||
| TEMP. COEFFICIENT | ± °C °C) 0.03%/ (0 ~ 50 on Load output | ||||||
| VIBRATION | 10 ~ 500Hz, 5G 10min./1cycle, 60min. each along X, Y, Z axes | ||||||
| OPERATING ALTITUDE Note.8 | 2000 meters / OVC III. | ||||||
| OVER VOLTAGE CATEGORY | III.; According to Dekra BS EN/EN62368-1; altitude up to 2000 meters | ||||||
| OTHERS | |||||||
| DIMENSION | 85.5*125.2*129.2mm (W*H*D) | ||||||
| MTBF | 564.7K hrs min. Telcordia SR-332 (Bellcore); 73.3K hrs min. MIL-HDBK-217F (25 ) °C | ||||||
| PACKING | 1.19Kg; 8pcs/ 12.5Kg/1.08CUFT | ||||||
| FUNCTION | |||||||
| DC OK | Signals normal DC output and activates when output voltage > 90% rated value. Relay contact output, ON : DC OK ; OFF: DC Fail ; max. rating : 30Vdc/1A | ||||||
| AC FAIL | Signals AC failure and activates when input voltage drops below : 79~89VAC of 120AC, 132~187VAC of 220VAC. Relay contact output, ON : AC OK ; OFF: AC Fail ; max. rating : 30Vdc/1A | ||||||
| BATTERY LOW/ABNORMAL/DISCONNECTED | Relay contact output, ON : Battery OK ; OFF: Battery Low ; max. rating : 30Vdc/1A | ||||||
| CHARGER FAIL | Relay contact output, ON : Charger OK ; OFF : Charger Fail ; max. rating : 30Vdc/1A | ||||||
| RELAY | FORM-C | ||||||
| DC-UPS | UPS switch to battery power within 10ms of AC failure | ||||||
| ADJUSTABLE CHARGING CURRENT | BATTERY CURRENT (CC)(MAX.) 15.4A 7.7A 5.1A 3.85A | ||||||
| BATTERY START | Restart system directly from battery and does not require AC power | ||||||
| REVERSE POLARITY | By internal MOSFET, recovers automatically after fault condition is removed. No damage | ||||||
| BATTERY TEMPERATURE COMPENSATION | The system can change the battery charging voltage by detecting the temperature (Please refer to page 9~10 for more details). | ||||||
| Load main output | 16.2~18.6V/32.4~37.3V/48.6~55.9V/64.8~74.5V | ||||||
