DDR-120C-48
MEANWELL
1
DC-DC Ultra slim Industrial DIN rail converter, Input 33.6-67.2VDC, Single Output 48VDC / 2.5A
DIN RAIL > DR
* Brand new product in its original packaging covered by the warranties and certifications provided by MEANWELL
Thank you for your interest in our products; we hope the delivery time indicated is to your convenience.
While the order is being processed you can select the type of shipment that best suits your needs: 24-hour air express, standard 48-72 hour land, etc.
Name | DDR-120C-48 |
---|---|
Long Description | Dc/DC converter for din rail. Wide input range and operating temperature. Format to install on a Din rail. Input range33,6-67,2 Vdc. Output voltage48vdc. Adjustable by potentiometer (48-56Vcc). Output intensity2,5 A.Range of output current 0-2,5 a according To demand load. Output intensity3,75 Towith a maximum load capacity of 150%. Power:120W. Power:180Wduring 3s 48-56Vcc. Efficiency typical:92%. Protected against reverse polarity input transistor, with automatic recovery. Protection for low input voltage. Protection against short-circuits and overloads. Reinforced insulation input-output 4000Vcc. CEM EN55032 Class B. Operating temperature range from-40ºCup+70ºC.Consult the technical data sheet to see the curves of drift. Dimensions (Width x Height x depth) [mm]:32 x 125,2 x 102. 3 years warranty. Manufacturer: MEAN WELL. The converters of the series DDR-120 have a compact size with an input range 2 to 1. The power reserves of up to 150% support the starting of heavy loads such as motors DC or capacitive loads. In many cases this allows the use of a model of less power which saves space and money. A high immunity to transients and power peaks, as well as low electromagnetic emissions easier to use in almost all possible environments. They also have a wide range of operating temperature. The entrance is protected from a failed connection of the polarity by using a transistor, which prevents any damage against a possible bad connection. They have a reinforced insulation between input and output of 4000Vcc and a very low level of electromagnetic emission, in compliance with the class B rules EN55032. These converters have been designed to install on a Din rail. The output voltage can be adjusted using a potentiometer. Provide an isolated output, and stabilized. It allows us to give an output reliable when we have an entry from a battery or from any other computer that can easily swing in addition to achieve isolation between the input and the output. Series DDR has multiple utilities, both in the industrial sector, as in telecommunications applications. Suitable for industrial control systems, computers, semiconductor manufacturing, industrial automation, wireless networks and systems for telecom or datacom. |
Country of Origin | China |
Manufacturer | MEAN WELL |
Product type | Dc/DC converters |
Format | Din Rail |
Subformato | Narrow |
Applications | Building automation, Industrial, Telecommunications |
Series | DDR-120 |
State | New |
Warranty (Years) | 3,00 |
Height (mm) | 125.20 |
Width (mm) | 32.00 |
Long/Background | 102.00 |
Input range | 2:1 |
Range DC Input | 33,6, 35, 36, 36,4, 38,4, 40, 43, 46,8, 50, 50,4, 52, 56, 60, 62,4, 64,4, 67,2 |
DC input Min | 33,60 |
DC input Max | 67,20 |
Input connector | Screw-Type |
Output voltage | 48,00 |
Power (W) | 120,00 |
Peak Power (W) | One hundred eighty |
Output connector | Screw-Type |
Isolation (V) | 4.000,00 |
Approvals | EC, EAC, EN50155 |
Title: | Size: | Type: |
---|---|---|
PDF CATALOGUE LED MEANWELL EN.pdf | 5 Mbytes | |
PDF CATALOGUE POWER SUPPLY MEANWELL EN.pdf | 7 Mbytes |
