661664 LEGRAND URAONE PLATE PICTOGRAM
661664
LEGRAND
URAONE PLATE PICTOGRAM
Signalling plate URA ONE - vertical transparent plate for evacuation
URA ONE pictogram plate - surface installation
Accessories for lighting > Mechanical accessories/spare parts for luminaires
PRESCRIPTION OF EMERGENCIES
Brand new product in its original packaging covered by the warranties and certifications provided by LEGRAND
Best sellers
▲More info
▲- Pack (number of units)1
- Volume (dm3)1.586
- Weight (g)73.00
Signalling plate
- Vertical transparent plate for evacuation signalling (must be completed with adhesive evacuation label)
- LED non-maintained and maintained units
- Certified to IEC and EN 60598-2-22 standards
- High power LEDs with optimized lighting distribution
- Low consumption switching power supply. Fully recyclable
- Plug-in back with pre-cutted holes grid to ease installation and maintenance
- Automatic terminals with high capacity: 2 x 2.5mm². IP 42 - IK 07
- Duration: 1 and 3 hours. Ni-Cd or Ni-MH batteries. Recharge time: 24 hours. Charge monitor with a green LED. Opal diffuser
- Power supply: 230 V~ ± 10% - 50/60 Hz. Class II
- Flat flush-mounting integration into ceiling and wall with flush-mounting frame Cat.Nos 6 616 50/51
- Decorative frame to enhance surface-mounting aesthetic integration Cat.Nos 6 616 54/55
| Feature Name | Feature Value |
|---|---|
| Material (EF002169) | Plastic |
| Colour (EF000007) | White |
| Type of accessory/spare part (EF000215) | Other |
| Width (EF000008) | 142 mm |
| Length (EF001438) | 214.6 mm |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| 661664 EN_661664.pdf | 129 Kbytes |
 |
