LAPPAccessories61742425 PROTECT Box 2.4/1.2 BK LAPP Shrink tube PROTECT Box 2.4/1.2 BK
LAPP 61742425 61742425 PROTECT Box 2.4/1.2 BK - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

61742425 PROTECT Box 2.4/1.2 BK LAPP Shrink tube PROTECT Box 2.4/1.2 BK

Reference: 61742425

Catalog Number: PROTECT Box 2.4/1.2 BK

Manufacturer: LAPP

Description:

Shrink tube PROTECT Box 2.4/1.2 BK
Shrink tube PROTECT Box

Categories:

  • Installation, isolation and connection material > Shrink tubing
  • LAPP > Accessories

Brand new product in its original packaging covered by the warranties and certifications provided by LAPP

  • More Info
  • PDF
  • Reviews
Guarantee, repair and return.

Unit Price: 12,03 €

This price is per unit and is the net value (not including taxes if applicable).

Calculate price by quantity

QuantityPrice

Standard lead time: 1 week.

  • These delivery times are an estimate any may vary when the item order has been processed.

LAST VIEWED

MORE INFO

The shrinkable plastic conduit in an handy box is especially suitable for small-scale consumers.

Thin walled

Benefits

  • Flexible
  • Excellent physical and mechanical properties
  • Approved for the use in North America and Canada

Application range

  • Insulation, protection and cable bundling
  • Green-yellow shrink tube: For identifying and marking earthing connectors and cables

Product features

  • Flame-retardant (except colour: clear)
  • Silicone-free
  • UV-resistant (only colour: black)

Norm references / Approvals

  • UL 224 approval (except colour: transparent)
  • UL file no.: E476215 (except colour: transparent)

Note

  • Not resistant against engine oils

Included

  • Stackable boxes for easy storage

Classification ETIM 5

  • ETIM 5.0 Class-ID: EC000217
  • ETIM 5.0 Class-Description: Heat-shrink tubing

Classification ETIM 6

  • ETIM 6.0 Class-ID: EC000217
  • ETIM 6.0 Class-Description: Shrink tubing

On request

  • Other colours are available upon request

Note

  • Thin walled
  • Dielectric strength: 20 kV/mm

Info

  • Shrinking ratio: 2:1

Colour delivered

  • Black
    Transparent
    Green-yellow

Material

  • Cross-linked polyolefin

Temperature range

  • -55°C to +135°C
  • Shrinking temperature: +90°C

DATASHEET - PDF

Title
Size
Type
61742425 61742425 EN_61742423.pdf
359 Kbytes
PDF CATALOGUE LAPP EN
69 Mbytes
