> LAPP>SKINTOP cabling>53112960 SKINTOP MS-SC NPT 1 1/2" LAPP SKINTOP MS-SC NPT 1 1/2"
Previous Product Next Product
53112960 SKINTOP MS-SC NPT 1 1/2" LAPP SKINTOP MS-SC NPT 1 1/2" View larger
Images are for illustrative purposes only. Please refer to data sheet for details.

53112960 SKINTOP MS-SC NPT 1 1/2" LAPP SKINTOP MS-SC NPT 1 1/2"

53112960

SKINTOP MS-SC NPT 1 1/2"

LAPP

5

SKINTOP MS-SC NPT 1 1/2"

SKINTOP® MS-SC NPT

More details


Cable and wire entry systems > Cable gland

SKINTOP cabling

* Brand new product in its original packaging covered by the warranties and certifications provided by LAPP

Total price: $144.06
Unit price: $28.81

Quantity Price
5+$28.81
10+$24.55
15+$22.75
20+$22.09
25+$22.09
*This price is per unit and is the net value (not including taxes if applicable).

If our price is not the best, please ask us for a quote. Ask for a quotation

Best sellers

▲

More info

▲


SKINTOP® MS-SC NPT, brass cable gland with highly conductive, flexible EMC contact, for cables with and without inner sheath

Benefits

  • Low-resistance screen contact, optimum EMC protection
  • Suitable for cables with and without inner sheath
  • Also suitable for continuing the cable screen to another connection
  • Highly conductive, flexible EMC contact for clamping various screen diameters
  • Few operation steps, easy to assemble

Application range

  • For EMC-compliant earthing of the copper braiding
  • Automation technology
  • Telecommunication
  • Measurement and control technology
  • Industrial machinery and plant engineering

Norm references / Approvals

  • UL File Nr. E79903

Product Make-up

  • NPT connection thread acc. to ASME B1.20.1 - 2013

Classification ETIM 5

  • ETIM 5.0 Class-ID: EC000441
  • ETIM 5.0 Class-Description: Cable screw gland

Classification ETIM 6

  • ETIM 6.0 Class-ID: EC000441
  • ETIM 6.0 Class-Description: Cable screw gland

Material

  • Body: nickel-plated brass
    Insert: polyamide
    Sealing: CR
    O-ring: NBR

Protection rating

  • IP 68 - 10 bar
  • NEMA Type 1, 4x, 6, 12

Temperature range

  • Dynamic: -25°C up to +100°C
  • Fixed: -40°C up to +100°C

Datasheet - PDF

▲
Title: Size: Type:
PDF CATALOGUE LAPP EN.pdf 58 Mbytes
53112960 SKINTOP MS-SC NPT 1 1/2" 53112960 EN_53112910.pdf 568 Kbytes 53112960 SKINTOP MS-SC NPT 1 1/2
