2170893 ETHERLINE Y FC Cat.5 LAPP ETHERLINE Y FC Cat.5

Benefits

• Can be used in dry or damp rooms
• Screened against interference
• Can be used for Industrial Ethernet in harsh industrial environments
• 2pair: 10/100 Mbit/s for Industrial Ethernet

Application range

• for industrial secondary and tertiary cabling according to EN 50173-3
  ISO/IEC 24702
• Wiring of machines, tools, devices, appliances and control cabinets
• suitable for EtherCAT and EtherNet/IP applications
• ETHERLINE® TRAY ER PN Y FC: installation in open cable trays without any conduit

Product features

• Fixed Installation
• CAT.5-Performance
• FC: "Fast Connect" cable design
• ETHERLINE® Y FC, ETHERLINE® YY, ETHERLINE® TRAY ER PN Y FC : flame-retardant according to CSA FT-4

Norm references / Approvals

• Flame retardant acc. to IEC 60332-1-2
• ETHERLINE® Y FC with PLTC approbation and AWM Style 21694
• ETHERLINE® PN Cat.5e YY with UL CMG
• ETHERLINE® PN Cat.5e Y with UL CMX
• ETHERLINE® TRAY ER PN Y FC with PLTC ER approval

Product Make-up

• Version for outdoor use: Colour black (similar to RAL 9005)
• Solid bare copper wire AWG22
• Core insulation: PE
• Star quad
• Overall screening with copper braid and plastic-laminated aluminium foil
• Outer sheath: PVC
• Colour: green (based on RAL 6018)

Classification ETIM 5

• ETIM 5.0 Class-ID: EC000830
• ETIM 5.0 Class-Description: Data cable

Classification ETIM 6

• ETIM 6.0 Class-ID: EC000830
• ETIM 6.0 Class-Description: Data cable

Peak operating voltage

• (not for power applications) 125 V

Minimum bending radius

• See data sheet

Test voltage

• See data sheet

Characteristic impedance

• nom. 100 Ω acc. to IEC 61156-5

Temperature range

• See data sheet
