2170006 RG-214 /U LAPP Coaxial RG-214 /U
2170006
RG-214 /U
LAPP
100 m.
Coaxial - RG-214 /U
Coaxial - RG
Cables > Coaxial cable
UNITRONIC LAN cabling
Brand new product in its original packaging covered by the warranties and certifications provided by LAPP
Best sellers
▲More info
▲Fixed installation and conditional flexible use in dry or damp interiors and outdoors. Temperature range from -55°C to +250°C
Benefits
- Coaxial cables allow distortion-free and low-attenuation transmission of signals with a high bandwidth.
- High frequencies
Application range
- For applications with limited movements and for fixed installation in dry or damp interiors and outdoors
- For radio and computer systems, as well as all applications related to commercial radio-frequency technology and electronics
Product features
- Flame-retardant
Product Make-up
- Coaxial cables are significantly less sensitive to external interference due to their structure.
Classification ETIM 5
- ETIM 5.0 Class-ID: EC000019
- ETIM 5.0 Class-Description: Coaxial cable
Classification ETIM 6
- ETIM 6.0 Class-ID: EC000019
- ETIM 6.0 Class-Description: Coaxial cable
Dielectric constant
- - Polyethylene (PE) 2.3
- Polyethylene, hollow (PE-ho) 1.5
- Polytetrafluoroethylene (PTFE) 2.1
Minimum bending radius
- Fixed installation: 6 x outer diameter
Specifications and approvals
- Similar to MIL-DTL17 H
Temperature range
- Fixed installation: PE outer sheath:
-40°C to +80°C - Fixed installation: PVC outer sheath:
-40°C to +80°C
Fixed installation: fluoroplastic
-55°C to +250°C
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE LAPP EN.pdf | 69 Mbytes |
|
| 2170006 RG-214 /U 2170006 EN_2170003.pdf | 357 Kbytes |
|
