413096 IME TRANSF SAFETY 12/24 25VA
Code: 413096
Manufacturer: IME
Description:
TRANSF SAFETY 12/24 25VA
Safety Transformer - 230V/12 or 24V - 25VA
Categories:
- Devices for distribution board-/surface mounting > Bell transformer
- IME
Brand new product in its original packaging covered by the warranties and certifications provided by IME
- More Info
- ETIM
- Reviews
* This article may be obsolete. Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.
Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.
MORE INFO
Safety transformer 12/24 25VA. Safety transformers - Comply with EN/IEC 61558-2-6 standard - Protected against overloads and short circuits by CTP - In case of automatic overload cut, interrupt the power and let the transformer cool down before starting it up again - wall mounting or on a symmetrical rail (for 4 modules) 230V/12 or 24V - By 2x12V coupling for ref. 4 130 97 and 4 130 98 with included power strips - P: 25VA - No-load loss: 2.5 W - Voltage drop Cos phi = 1: 29 % - Rend. Cos phi= 1: 66 % - Ucc: 23.3 % - I prim. under load: 0.14A - Number of modules: 4. Transformers, bells and buzzers - Equipped with label holders.
| Primary voltage | 230 V |
|---|---|
| Secondary Voltage 1 | 12 V |
| Secondary Voltage 2 | 24 V |
| Maximum power output | 25 W |
| Maximum power loss | 2.5 W |
| Transformer Type | Safety Transformer |
| Surface mounting | Yes |
| Flush mounting | Yes |
| Suitable for series installation | Yes |
|---|---|
| Longitude | 72 mm |
| Width | 66 mm |
| Height | 84 mm |
| Width in number of modular spaces | 4 |
| Short circuit protected | Yes |
| Temperature protection | Yes |
| With on/off switch | No |
ETIM for 413096 Modular devices for distribution board/surface mounting (EC001547)
Feature name
Feature value
Feature nameTemperature protection (EF003782)
Feature valueYes
Feature nameHeight (EF000040)
Feature value84 mm
Feature nameSurface mounting (EF003681)
Feature valueYes
Feature nameWidth in number of modular spacings (EF002950)
Feature value4
Feature namePrimary voltage (EF003775)
Feature value230 V
Feature nameMax. power loss (EF004996)
Feature value2.5 W
Feature nameSecondary voltage 1 (EF003776)
Feature value12 V
Feature nameShort-circuit protected (EF003696)
Feature valueYes
Feature nameWith on/off switch (EF000488)
Feature valueNo
Feature nameModular version (EF001126)
Feature valueYes
Feature nameType of transformer (EF000279)
Feature valueSafety transformer
Feature nameSecondary voltage 2 (EF003777)
Feature value24 V
Feature nameFlush-mounted installation (EF007517)
Feature valueYes
Feature nameWidth (EF000008)
Feature value66 mm
Feature nameLength (EF001438)
Feature value72 mm
Feature nameMax. output power (EF001507)
Feature value25 W
