PGM10066
ELDON
1
Available Ship on today
Socket, 1000x600x600, galvanized steel, RAL7035
Cables can be easily routed through the ground plinth, which is mounted underground, allowing cables to be channelled and therefore, wired more quickly.
Cabinet enclosures > Base/base element (switchgear cabinet)
Steel Floor Standing Enclosures
* Brand new product in its original packaging covered by the warranties and certifications provided by ELDON
Thank you for your interest in our products; we hope the delivery time indicated is to your convenience.
While the order is being processed you can select the type of shipment that best suits your needs: 24-hour air express, standard 48-72 hour land, etc.
Description: | Ground mounted plinth 1000 mm height. Excavation depth: 700-950 mm. |
Material: | 2 mm galvanized steel. |
Finish: | RAL 7035 polyester powder coated. |
Pack quantity: | 1 kit of ground mounted plinth. |
Feature: | Galvanized steel ground mounted plinth for aluminium floor standing enclosures. |
Advantage: | The ground plinth can be mounted 700-950 mm underground, which allows cables to be easily routed in and out of the enclosure. |
Benefit: | Outdoor aluminium EKOM enclosures can be easily installed in the field thanks to the installation depth of the ground plinth. Cables that are channelled underground can be wired much quicker than if they had to be brought to the surface first. |
Comment: | For the installation of UDP polyester modular wall mounted enclosures in the base is required the adaptor frame UAF. |
Title: | Size: | Type: |
---|---|---|
PDF CATALOGUE NVENT EN.pdf | 76 Mbytes | |
PGM10066 PGM10066 EN_PGM10064.pdf | 85 Kbytes | |
Download general catalog |
