MSPS2005 ELDON Panels lat. internal,2000x500, for each section of the wires, d 537
MSPS2005
ELDON
Panels lat. internal,2000x500, for each section of the wires, d=537
Internal side panels, 2000x500, for cables section, d=537
Cabinet enclosures > Side/back panel (switchgear cabinet)
Power and distribution
Brand new product in its original packaging covered by the warranties and certifications provided by ELDON
Best sellers
▲More info
▲Features
- Description: Internal side panels to build up sections as from the enclosure frame. Frame hole pattern is needed in front, rear, top and bottom.
- Material: 1.5 mm galvanized steel.
- Delivery: 1 piece with mounting material.
- The side panels segregate vertical sections, allowing customer's to mount main busbar supports (MSHS) and other accessories
- A flexible solution for both fix and plug-in systems
- The side panels allow customers to build up power distribution configurations to meet form 4 segregation according to IEC 61439
- Hole patterns are required in the top, bottom, front and rear of the enclosure, in order to mount the internal side panels
| Atributo del producto | Valor |
|---|---|
| Height | 2000 mm |
| Width | 88.5 mm |
| Depth | 500 mm |
| Panel Size | 2000 x 337 mm |
| Usage | Cables Section |
| Enclosure Material | Mild Steel |
| Product Family | Free-Standing |
| Material | Steel |
| Finish | Galvanized |
| Color | Unpainted |
| Thickness | 1.5 mm |
| UPC | 783510522322 |
| EAN | 8713574194724 |
| Standard Packaging Quantity | 1.0000 |
| Packing Quantity | 1.0000 |
| Feature Name | Feature Value |
|---|---|
| Suitable as side panel (EF008287) | |
| Suitable as rear panel (EF008288) | |
| Modular spacing (EF000394) | None mm |
| Suitable for enclosure building width (EF000326) | None mm |
| Suitable for enclosure building depth (EF000327) | None mm |
| Width (EF000008) | 500.00 mm |
| Height (EF000040) | 2.00 mm |
| Material (EF002169) | |
| Surface finishing (EF006569) | |
| Colour (EF000007) | |
| RAL-number (EF000116) | |
| With cable entry (EF000325) | |
| Number of height units (EF003561) | |
| With lock (EF006306) |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE NVENT EN.pdf | 140 Mbytes |
|
| MSPS2005 MSPS2005 EN_MSPS1803.pdf | 117 Kbytes |
|
| Download general catalog |
|
