MSMCP6008R5 ELDON Front Panel modular, 600x800, 4 DIN rail, 144 modules
MSMCP6008R5
ELDON
Front Panel modular, 600x800, 4 DIN rail, 144 modules
Modular front panel, 600x800, 4 DIN rails
Cabinet enclosures > Front plate (switchgear cabinet)
Power and distribution
Brand new product in its original packaging covered by the warranties and certifications provided by ELDON
Best sellers
▲More info
▲Features
- Description: Slotted front panel for modular assemblies. Provided with one DIN rail per row for modular components. It has a top and bottom bending to provide extra rigidity.
- Material: 1.25 mm steel.
- Finish: RAL 7035 structured powder coating.
- Delivery: 1 piece with mounting material.
- Mounting requirements: To be assembled on the modular system frame.
- The panels are to be mounted onto a fix system front frame (MSFCP) or onto modular system frames (MSMSF or MSMSM)
- Slotted front panel for modular assemblies
- Provided with one DIN rail per row for modular components
- It has a top and bottom bending to provide extra rigidity
- One piece with mounting material
- To be assembled on the modular system frame
| Atributo del producto | Valor |
|---|---|
| Height | 600mm |
| Width | 800mm |
| Depth | 13mm |
| Enclosure Material | Mild Steel |
| Product Family | Free-Standing; Wall Mounted |
| Material | Mild Steel |
| Finish | Powder Coated |
| Color | Light Gray |
| Color Code | RAL 7035 |
| Thickness | 1.25mm |
| Panel Quantity | 4 |
| DIN Rail | 152 |
| UPC | 783510518660 |
| EAN | 8713574214262 |
| Standard Packaging Quantity | 1 |
| Packing Quantity | 1 |
| Feature Name | Feature Value |
|---|---|
| Width (EF000008) | 800.00 mm |
| Height (EF000040) | 600.00 mm |
| Suitable for enclosure building width (EF000326) | None mm |
| Suitable for enclosure building height (EF009583) | None mm |
| Number of height units (EF003561) | |
| Material (EF002169) | |
| Surface finishing (EF006569) |
