ELDONGeneral AccessoriesEFE200R5 ELDON Filter Fan EMC 61 m3/h EFE200R5
ELDON EFE200R5 EFE200R5 - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

EFE200R5 ELDON Filter Fan EMC 61 m3/h EFE200R5

Reference: EFE200R5

Manufacturer: ELDON

Description:

Filter Fan EMC 61 m3/h EFE200R5
Fan filter ECM 61 m3/h, 230 V, IP54
Filter Fan EMC 61 m3/h, 230V, IP54

Categories:

  • Cabinet enclosures > Ventilator (switchgear cabinet)
  • ELDON > General Accessories

Brand new product in its original packaging covered by the warranties and certifications provided by ELDON

  • More Info
  • ETIM
  • PDF
  • Reviews
Guarantee, repair and return.

Unit Price: 238,75 €

This price is per unit and is the net value (not including taxes if applicable).

Calculate price by quantity

QuantityPrice

Standard lead time: 10 days.

  • These delivery times are an estimate any may vary when the item order has been processed.

MORE INFO

Features

  • Description: EMC capable filter fan. Special EMC screen in combination with stainless steel contact strips guarantee good contact with enclosure surface. Cutting edge surface of the enclosure needs to be blank for contact. Long service life.
  • Approvals: CE, GOST, UR, cUL.
  • Material: Plastic, UL 94-V0. EMC screen: stainless steel, contact strips.
  • Pack quantity: 1 fan with filter.
  • The filter fan is reliable due to its high quality motor, as well as being easy to install
  • EMC performance is maintained when installed on an EMC enclosure
  • Component failure and unnecessary downtime is avoided as water, dust and electromagnetic interferences are prevented from entering the enclosure and the reliable motor ensures that there is constant ventilation
  • The click-in feature reduces the customer's labour cost due to the ease of installation
  • The filter fan should be installed together with at least one exhaust filter, EFAE
  • Filter mat (EN779) G4
  • Bearing Type: Sleeve
Atributo del producto Valor
Height145mm
Width145mm
Depth70mm
Power @ 50 Hz19W
Power @ 60 Hz18W
Airflow Volume, With Filter metric44/52m³/h
Aiflow Volume, Without Filter61/70m³/h
Lifespan, L10 @ 40 C37500h
Enclosure Cutout126.5 x 126.5mm
Connection TypeTerminal Strip
Nominal Current0.12/0.18A
MaterialPlastic
FinishTextured
ColorLight Gray
Nominal Voltage230V
Frequency50/60Hz
Filter Efficiency90%
Noise Level44dB
Protection Fuse6A
Protection RatingIP54
Weight0.8kg
UPC783510475659
EAN8713574131958
Standard Packaging Quantity1
Packing Quantity1

ETIM for EFE200R5 Cabinets and enclosures (EC000320)

Feature nameNumber of fans (EF000928)
Feature value1.00
Feature nameOperating voltage AC 50 Hz (EF008206)
Feature value230.00 V
Feature nameOperating voltage AC 60 Hz (EF008207)
Feature value230.00 V
Feature nameVoltage type (EF000187)
Feature valueAC
Feature nameBuilt as slide-in ventilator (EF007126)
Feature valueYes
Feature nameAir circulator (EF007516)
Feature valueNo
Feature nameRoof ventilator (EF007099)
Feature valueNo
Feature nameWith filter (EF006013)
Feature valueYes
Feature nameVolume flow, freeblowing (EF007173)
Feature value61.00 m³/h
Feature nameRated power (EF007051)
Feature value19.00 W
Feature nameEMC-version (EF001062)
Feature valueYes
Feature nameDegree of protection (IP) (EF005474)
Feature valueIP54
Feature nameMounting method (EF000003)
Feature valueSnap mounting
Feature nameSuitable for 19 inch rack mounting (EF000337)
Feature valueNo
Feature nameColour (EF000007)
Feature valueGrey
Feature nameRAL-number (EF000116)
Feature value7.04
Feature nameWidth (EF000008)
Feature value145.00 mm
Feature nameHeight (EF000040)
Feature value145.00 mm
Feature nameDepth (EF000049)
Feature value84.00 mm
