EFE500R5 ELDON Filter Fan EMC 480 m3/h EFE500R5
EFE500R5
ELDON
Filter Fan EMC 480 m3/h EFE500R5
Fan filter ECM 480 m3/h, 230 V, IP54
Filter Fan EMC 480 m3/h, 230V, IP54
Cabinet enclosures > Ventilator (switchgear cabinet)
General Accessories
Brand new product in its original packaging covered by the warranties and certifications provided by ELDON
Best sellers
▲More info
▲Features
- Description: EMC capable filter fan. Special EMC screen in combination with stainless steel contact strips guarantee good contact with enclosure surface. Cutting edge surface of the enclosure needs to be blank for contact. Long service life.
- Approvals: CE, GOST, UR, cUL.
- Material: Plastic, UL 94-V0. EMC screen: stainless steel, contact strips.
- Pack quantity: 1 fan with filter.
- The filter fan is reliable due to its high quality motor, as well as being easy to install
- EMC performance is maintained when installed on an EMC enclosure
- Component failure and unnecessary downtime is avoided as water, dust and electromagnetic interferences are prevented from entering the enclosure and the reliable motor ensures that there is constant ventilation
- The click-in feature reduces the customer's labour cost due to the ease of installation
- The filter fan should be installed together with at least one exhaust filter, EFAE
- Filter mat (EN779) G4
- Bearing Type: Sleeve
| Atributo del producto | Valor |
|---|---|
| Height | 320mm |
| Width | 320mm |
| Depth | 155mm |
| Power @ 50 Hz | 80W |
| Power @ 60 Hz | 100W |
| Airflow Volume, With Filter | 370/370m³/h |
| Aiflow Volume, Without Filter | 480/480m³/h |
| Lifespan, L10 @ 40 C | 40000h |
| Enclosure Cutout | 292 x 292mm |
| Connection Type | Spring Type |
| Nominal Current | 0.35/0.45A |
| Material | Plastic |
| Finish | Textured |
| Color | Light Gray |
| Nominal Voltage | 230V |
| Frequency | 50/60 HzHz |
| Filter Efficiency | 90% |
| Noise Level | 54dB |
| Protection Fuse | 6A |
| Protection Rating | IP54 |
| Weight | 3.85kg |
| UPC | 783510475772 |
| EAN | 8713574132061 |
| Standard Packaging Quantity | 1 |
| Packing Quantity | 1 |
| Feature Name | Feature Value |
|---|---|
| Number of fans (EF000928) | 1.00 |
| Operating voltage AC 50 Hz (EF008206) | 230.00 V |
| Operating voltage AC 60 Hz (EF008207) | 230.00 V |
| Voltage type (EF000187) | AC |
| Built as slide-in ventilator (EF007126) | Yes |
| Air circulator (EF007516) | No |
| Roof ventilator (EF007099) | No |
| With filter (EF006013) | Yes |
| Volume flow, freeblowing (EF007173) | 480.00 m³/h |
| Rated power (EF007051) | 115.00 W |
| EMC-version (EF001062) | Yes |
| Degree of protection (IP) (EF005474) | IP54 |
| Mounting method (EF000003) | Snap mounting |
| Suitable for 19 inch rack mounting (EF000337) | No |
| Colour (EF000007) | Grey |
| RAL-number (EF000116) | 7.04 |
| Width (EF000008) | 320.00 mm |
| Height (EF000040) | 320.00 mm |
| Depth (EF000049) | 157.00 mm |
