CPG16 ELDON Cable plastic glands M16 50pcs CPG16
CPG16
ELDON
Cable plastic glands M16 50pcs CPG16
Cable glands plastic M16, 50 or.. Pack of 50 units.
Cable and wire entry systems > Cable gland
General Accessories
Brand new product in its original packaging covered by the warranties and certifications provided by ELDON
Best sellers
▲More info
▲Features
- Description: Traditional cable fittings. Known for excellent strain relief even while providing a high protection class. Plastic lock nuts for fixation are included in the delivery.
- Material: Fitting body made of polyamide PA6, and sealing made of neoprene.
- Temperature resistance: -20ºC to +100ºC.
- Flammability: V-2 according to UL94.
- Finish: RAL 7035.
- Protection: IP 66
| Atributo del producto | Valor |
|---|---|
| Height | 40mm |
| Width | 22mm |
| Depth | 24mm |
| Enclosure Material | Mild Steel |
| Product Family | Wall Mounted |
| Material | Polyamide 6; Neoprene |
| Finish | Smooth |
| Color | Light Gray |
| Color Code | RAL 7035 |
| Thread Size | M16 x 1.5 |
| Cable Diameter Range | 5 – 10mm |
| Package Quantity | 50 |
| UPC | 783510461324 |
| EAN | 8713574187139 |
| Standard Packaging Quantity | 1 |
| Packing Quantity | 50 |
| Feature Name | Feature Value |
|---|---|
| Thread type (EF001758) | Metric |
| Nominal thread size metric/PG (EF007839) | 16.00 |
| Suitable for cable diameter (EF005466) | 5.00 mm |
| Material (EF002169) | Plastic |
| Material quality (EF001257) | Polyamide (PA) |
| Surface protection (EF000139) | Untreated |
| Halogen free (EF000025) | No |
| Glass-fibre reinforced (EF001210) | No |
| Degree of protection (IP) (EF005474) | IP68 |
| Shock resistant (EF000084) | No |
| Colour (EF000007) | Grey |
| RAL-number (EF000116) | 7.04 |
| Bend radius protection/trumpet flare (EF000734) | No |
| With locknut (EF005049) | No |
| Model (EF000010) | Straight |
| Multi seal area (EF005004) | No |
| Flat cable coupling (EF004685) | No |
| With strain relief (EF000878) | Yes |
| Type of sealing (EF001217) | EV009696 |
| Separable screw gland (EF005337) | No |
| Explosion-tested version (EF004191) | No |
| For Ex-zone gas (EF005728) | None |
| For Ex-zone dust (EF008404) | None |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE NVENT EN.pdf | 140 Mbytes |
|
| CPG16 CPG16 EN_CPG12.pdf | 127 Kbytes |
|
| Download general catalog |
|
