CGHD16 ELDON Cable glands HD M16, 5pc CGHD16
CGHD16
ELDON
Cable glands HD M16, 5pc CGHD16
Knockouts HD M16, 5u. Pack of 5 units.
Cable glands HD M16, 5pc
Cable and wire entry systems > Cable gland
Stainless steel enclosures
Brand new product in its original packaging covered by the warranties and certifications provided by ELDON
Related products
▲Often bought together
▲Best sellers
▲More info
▲Features
- Description: Hygienic design cable fittings. Known for excellent strain relief even while providing higher protection class. Machining required. Design according to EHEDG standards.
- Material: AISI 303 stainless steel. Sealing in FDA approved silicone.
- Protection: IP 69.
- Pack quantity: 5 pieces, locknut included.
| Atributo del producto | Valor |
|---|---|
| Height | 30mm |
| Width | 20mm |
| Depth | 20mm |
| Enclosure Material | Stainless Steel |
| Product Family | Wall Mounted |
| Material | Stainless Steel 303 |
| Finish | Brushed |
| Thread Size | M16 x 1.5 |
| Cable Diameter Range | 5 – 10mm |
| UPC | 783510458140 |
| EAN | 8713574206434 |
| Standard Packaging Quantity | 1 |
| Packing Quantity | 5 |
| Feature Name | Feature Value |
|---|---|
| Thread type (EF001758) | Metric |
| Nominal thread size metric/PG (EF007839) | 16.00 |
| Suitable for cable diameter (EF005466) | 5.00 mm |
| Material (EF002169) | Metal |
| Material quality (EF001257) | Stainless steel 304 |
| Surface protection (EF000139) | Untreated |
| Halogen free (EF000025) | No |
| Glass-fibre reinforced (EF001210) | No |
| Degree of protection (IP) (EF005474) | IP69K |
| Shock resistant (EF000084) | Yes |
| Colour (EF000007) | Other |
| Bend radius protection/trumpet flare (EF000734) | No |
| With locknut (EF005049) | No |
| Snapping in opening (EF012547) | No |
| Model (EF000010) | Straight |
| Multi seal area (EF005004) | No |
| Flat cable coupling (EF004685) | No |
| With strain relief (EF000878) | No |
| Separable screw gland (EF005337) | No |
| Explosion-tested version (EF004191) | No |
| For Ex-zone gas (EF005728) | None |
| For Ex-zone dust (EF008404) | None |
| For armoured cable (EF012184) | Yes |
| EMC-version (EF001062) | No |
| Screened (EF000881) | No |
