ELDONGeneral AccessoriesCAG25 ELDON Cable anchorage gland M25 CAG25
ELDON CAG25 CAG25 - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

CAG25 ELDON Cable anchorage gland M25 CAG25

Reference: CAG25

Manufacturer: ELDON

Description:

Cable anchorage gland M25 CAG25
Cable glands with anchoring M25. Pack of 50 units.
Cable anchorage gland M25

Categories:

  • Cable and wire entry systems > Cable gland
  • ELDON > General Accessories

Brand new product in its original packaging covered by the warranties and certifications provided by ELDON

  • More Info
  • ETIM
  • PDF
  • Reviews
Guarantee, repair and return.

Unit Price: 42,67 €

This price is per unit and is the net value (not including taxes if applicable).

Calculate price by quantity

QuantityPrice

Standard lead time: 10 days.

  • These delivery times are an estimate any may vary when the item order has been processed.

MORE INFO

Features

  • Description: Two-component grommet with membrane seal and cable anchorage. The installation does not require tools, it is self-adjusting to its surrounding wall thickness and click-fixed in place. Because of its compact design it only extends 5.7 mm outside the enclosure on which it is mounted. The “pushout” membrane is a permanent seal until it is penetrated by a cable or pipe. Suitable for holes in materials of 0.7 to 3 mm thickness.
  • Material: TPE and polyamide 66, halogen free.
  • Temperature resistance: -20 ºC to +125 ºC.
  • Finish: RAL 7035.
  • Protection: IP 67, 65, waterproof.
  • Pack quantity: 50 pieces.
Atributo del producto Valor
Height (H)19.7mm
Width (W)35.7mm
Depth (D)35.7mm
Height (H)17 – 20mm
Diameter (Ø)39 – 42mm
Cable Diameter Range7 – 13mm
Hole Diameter25.5mm
Product FamilyWall Mounted
Enclosure MaterialMild Steel
MaterialPlastic
FinishSmooth
ColorLight Gray
Color CodeRAL 7035
UPC783510454753
EAN8713574187290
Standard Packaging Quantity1
Packing Quantity50

ETIM for CAG25 Cable glands and cable entry products (EC000441)

Feature nameThread type (EF001758)
Feature valueMetric
Feature nameNominal thread size metric/PG (EF007839)
Feature value25.00
Feature nameNominal thread size inch/gas pipe thread (EF007838)
Feature value
Feature namePitch thread (EF003712)
Feature valueNone mm
Feature nameThread length (EF000368)
Feature valueNone mm
Feature nameWrench width (EF000177)
Feature valueNone mm
Feature nameHexagon angular dimension (EF005268)
Feature valueNone mm
Feature nameSuitable for cable diameter (EF005466)
Feature value7.00 mm
Feature nameMaterial (EF002169)
Feature valuePlastic
Feature nameMaterial quality (EF001257)
Feature valuePolyamide (PA)
Feature nameSurface protection (EF000139)
Feature valueUntreated
Feature nameHalogen free (EF000025)
Feature valuefalse
Feature nameGlass-fibre reinforced (EF001210)
Feature valuefalse
Feature nameDegree of protection (IP) (EF005474)
Feature valueIP65
Feature nameShock resistant (EF000084)
Feature valuefalse
Feature nameColour (EF000007)
Feature valueGrey
Feature nameRAL-number (EF000116)
Feature value7.04
Feature nameBend radius protection/trumpet flare (EF000734)
Feature valuefalse
Feature nameWith locknut (EF005049)
Feature valuefalse
Feature nameSnapping in opening (EF012547)
Feature value
Feature nameModel (EF000010)
Feature valueStraight
Feature nameMulti seal area (EF005004)
Feature valuefalse
Feature nameFlat cable coupling (EF004685)
Feature valuefalse
Feature nameWith strain relief (EF000878)
Feature valuetrue
Feature nameType of sealing (EF001217)
Feature valueDiaphragm
Feature nameSeparable screw gland (EF005337)
Feature valuefalse
Feature nameOperating temperature (EF001742)
Feature valueNone °C
Feature nameExplosion-tested version (EF004191)
Feature valuefalse
Feature nameFor Ex-zone gas (EF005728)
Feature valueNone
Feature nameFor Ex-zone dust (EF008404)
Feature valueNone
Feature nameFor armoured cable (EF012184)
Feature value
Feature nameEMC-version (EF001062)
Feature value
Feature nameScreened (EF000881)
Feature value
